Digital Watchdog DWC-VSDG04BI MEGApix 4MP WDR Vandal Dome IP Camera with Smart IR, 2.8mm Fixed Lens, NDAA Compliant, White
Key Features
- Exceptional clarity for fast incident response: 4MP resolution at 30 fps with True WDR delivers usable color and detail in mixed lighting so you can identify people and events faster.
- Reliable 24/7 monitoring in any weather: IK10 vandal-resistant, IP67-rated aluminum housing stands up to impact, dust and moisture for outdoor and high-risk indoor installations.
- Nighttime performance with no extra lighting: Smart IR reaches up to 100' for clear B/W images in total darkness, reducing the need for external illumination.
- Intelligent analytics reduce false alerts: Built-in line crossing, perimeter intrusion and tamper detection focus attention on real threats and cut monitoring workload.
- Easy integration and procurement-ready: ONVIF conformity and NDAA compliance simplify system integration and public sector purchasing; supports common network protocols for fast deployment.
Quick Specifications
- Brand Name
- Digital Watchdog
- Manufacturer
- Digital Watchdog
- Product Line
- MEGApix
- Product Name
- MEGApix 4MP vandal dome IP camera with fixed lens and IR
Frequently Bought Together
Digital Watchdog DWC-VSDG04BI MEGApix 4MP WDR Vandal Dome IP Camera with Smart IR, 2.8mm Fixed Lens, NDAA Compliant, White
$191.21
14 items selected
Total: $15,645.99
Product Information Tabs
Overview
Built for dependable surveillance where image quality and durability matter, the Digital Watchdog MEGApix 4MP vandal dome IP camera (DWC-VSDG04BI) delivers clear, actionable video around the clock. Its 4MP sensor at real-time 30 fps and True WDR capture critical detail across bright and shadowed areas, while the 2.8mm fixed lens provides a wide field of view ideal for entrances, parking areas and retail floors. Housed in an IK10 impact-resistant, IP67 weatherproof aluminum dome, this camera withstands vandalism, dust and harsh environments so your security investment keeps protecting your site. Smart IR reaches up to 100 feet for reliable night monitoring without spotlighting, and on-board analytics — including line crossing, perimeter intrusion and tamper detection — reduce nuisance alarms and speed up incident review. ONVIF compatibility, NDAA compliance and support for common network protocols make integration into existing VMS and NVR systems straightforward. Backed by a 5-year limited warranty and flexible mounting, the DWC-VSDG04BI is ideal for business, education, transportation and government surveillance projects. Add this rugged MEGApix dome to your security system to improve monitoring, cut false alerts and secure critical areas today.
Features
- Exceptional clarity for fast incident response: 4MP resolution at 30 fps with True WDR delivers usable color and detail in mixed lighting so you can identify people and events faster.
- Reliable 24/7 monitoring in any weather: IK10 vandal-resistant, IP67-rated aluminum housing stands up to impact, dust and moisture for outdoor and high-risk indoor installations.
- Nighttime performance with no extra lighting: Smart IR reaches up to 100' for clear B/W images in total darkness, reducing the need for external illumination.
- Intelligent analytics reduce false alerts: Built-in line crossing, perimeter intrusion and tamper detection focus attention on real threats and cut monitoring workload.
- Easy integration and procurement-ready: ONVIF conformity and NDAA compliance simplify system integration and public sector purchasing; supports common network protocols for fast deployment.
| General Information | |
|---|---|
| Brand Name | Digital Watchdog |
| Manufacturer | Digital Watchdog |
| Product Line | MEGApix |
| Product Name | MEGApix 4MP vandal dome IP camera with fixed lens and IR |
| Product Type | Network Camera |
| Product Model | DWC-VSDG04BI |
| Product Series | V-Class |
| Manufacturer Part Number | DWC-VSDG04BI |
| Supported Network Protocols | IPv4, IPv6 |
| Technical Information | |
| Material | Aluminum Die-cast |
| Lens Type | Fixed |
| Protocols | 802.1x, DDNS, DHCP, FTP, HTTP, HTTPs, ICMP, IGMP, NTP, ONVIF, PPPoE, QoS, RTCP, RTP, RTSP, SMTP, SNMP, UDP, uPNP |
| Night Vision | Yes |
| Programmable | Yes |
| Field of View | Horizontal, Vertical |
| Video Formats | H.264, MJPEG |
| Output Voltage | 12V DC |
| Maximum Aperture | f/1.6 |
| Motion Detection | Yes |
| Night Vision Type | Infrared |
| Maximum Frame Rate | 30fps |
| Built-in Microphone | Yes |
| Minimum Focal Length | 2.8mm |
| Illumination Distance | 100' |
| Connectivity Technology | Wired |
| Effective Camera Resolution | 4MP |
| Audio | |
| Audio Encoding | G.711 |
| Memory Card Slot | Yes |
| Camera | |
| Image Sensor Type | CMOS |
| Wide Dynamic Range | Yes |
| Night Vision Distance | 100 ft |
| Certifications | |
| NDAA Compliant | Yes |
| Ingress Protection Rating | IP67 |
| Display & Graphics | |
| Image Sensor Size | 1/3" |
| Maximum Video Resolution | 1920 x 1080 |
| Environmental Conditions | |
| Operating Humidity | 0-95% RH (Non-condensing) |
| Operating Temperature (T-T) | -22-140°F |
| Maximum Operating Temperature | 140°F (60°C) |
| Minimum Operating Temperature | -22°F (-30°C) |
| Exposure | |
| Minimum Illumination | 0.0 lux (B/W), 0.005 lux (color) |
| Longest Shutter Speed | 1/2 Second |
| Shortest Shutter Speed | 1/100000 Second |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Lens | |
| Focus Modes | Auto, Manual |
| Focal Length | 2.8mm |
| Lens Included | Yes |
| Maximum Focal Length | 2.8mm |
| Media & Performance | |
| Network Technology | 10 Base, 100 Base |
| Network & Communication | |
| Remote Management | Yes |
| Physical Characteristics | |
| Color | White |
| Weight | 1.43 lb |
| Durability | Dustproof, Impact Resistant, Vandal Resistant, Waterproof, Weather Resistant |
| Form Factor | Dome |
| Power Description | |
| Input Voltage | 12V DC |
| Product Information | |
| Mount Type | Ceiling Mount, Junction Box Mount, Wall Mount |
| Storage | |
| Storage Type | Memory Card |
| Recording Formats | 2K |
| TBD | |
| Amperage | 375mA |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Warranty | |
| Limited Warranty | 5-Year |
| Miscellaneous | |
| Features | 3D Digital Noise Reduction, Auto Flip, Auto Gain Control, Back Light Compensation (BLC), Day/Night, Highlight Compensation (HLC), Human Detection, Mirror, Noise Reduction, Privacy Masking, Removable IR Cut-off Filter, White Balance |
| Certifications | CE, FCC, NDAA, ONVIF |
| Environmentally Friendly | Yes |
| Impact Protection Rating | IK10 |
| Environmental Certification | RoHS |
