Digital Watchdog DWC-VSDG04BI MEGApix 4MP WDR Vandal Dome IP Camera with Smart IR, 2.8mm Fixed Lens, NDAA Compliant, White

SKU: DWC-VSDG04BI Digital Watchdog
Image of 6K-VSDG04BI
Product images for Digital Watchdog DWC-VSDG04BI MEGApix 4MP WDR Vandal Dome IP Camera with Smart IR, 2.8mm Fixed Lens, NDAA Compliant, White. 1 image(s) available. Click on image to view full size.
NDAA Compliant

Key Features

  • Exceptional clarity for fast incident response: 4MP resolution at 30 fps with True WDR delivers usable color and detail in mixed lighting so you can identify people and events faster.
  • Reliable 24/7 monitoring in any weather: IK10 vandal-resistant, IP67-rated aluminum housing stands up to impact, dust and moisture for outdoor and high-risk indoor installations.
  • Nighttime performance with no extra lighting: Smart IR reaches up to 100' for clear B/W images in total darkness, reducing the need for external illumination.
  • Intelligent analytics reduce false alerts: Built-in line crossing, perimeter intrusion and tamper detection focus attention on real threats and cut monitoring workload.
  • Easy integration and procurement-ready: ONVIF conformity and NDAA compliance simplify system integration and public sector purchasing; supports common network protocols for fast deployment.

Quick Specifications

Brand Name
Digital Watchdog
Manufacturer
Digital Watchdog
Product Line
MEGApix
Product Name
MEGApix 4MP vandal dome IP camera with fixed lens and IR
View Full Technical Specifications

Frequently Bought Together

Product Information Tabs

Overview

Built for dependable surveillance where image quality and durability matter, the Digital Watchdog MEGApix 4MP vandal dome IP camera (DWC-VSDG04BI) delivers clear, actionable video around the clock. Its 4MP sensor at real-time 30 fps and True WDR capture critical detail across bright and shadowed areas, while the 2.8mm fixed lens provides a wide field of view ideal for entrances, parking areas and retail floors. Housed in an IK10 impact-resistant, IP67 weatherproof aluminum dome, this camera withstands vandalism, dust and harsh environments so your security investment keeps protecting your site. Smart IR reaches up to 100 feet for reliable night monitoring without spotlighting, and on-board analytics — including line crossing, perimeter intrusion and tamper detection — reduce nuisance alarms and speed up incident review. ONVIF compatibility, NDAA compliance and support for common network protocols make integration into existing VMS and NVR systems straightforward. Backed by a 5-year limited warranty and flexible mounting, the DWC-VSDG04BI is ideal for business, education, transportation and government surveillance projects. Add this rugged MEGApix dome to your security system to improve monitoring, cut false alerts and secure critical areas today.

Features

  • Exceptional clarity for fast incident response: 4MP resolution at 30 fps with True WDR delivers usable color and detail in mixed lighting so you can identify people and events faster.
  • Reliable 24/7 monitoring in any weather: IK10 vandal-resistant, IP67-rated aluminum housing stands up to impact, dust and moisture for outdoor and high-risk indoor installations.
  • Nighttime performance with no extra lighting: Smart IR reaches up to 100' for clear B/W images in total darkness, reducing the need for external illumination.
  • Intelligent analytics reduce false alerts: Built-in line crossing, perimeter intrusion and tamper detection focus attention on real threats and cut monitoring workload.
  • Easy integration and procurement-ready: ONVIF conformity and NDAA compliance simplify system integration and public sector purchasing; supports common network protocols for fast deployment.
General Information
Brand Name Digital Watchdog
Manufacturer Digital Watchdog
Product Line MEGApix
Product Name MEGApix 4MP vandal dome IP camera with fixed lens and IR
Product Type Network Camera
Product Model DWC-VSDG04BI
Product Series V-Class
Manufacturer Part Number DWC-VSDG04BI
Supported Network Protocols IPv4, IPv6
Technical Information
Material Aluminum Die-cast
Lens Type Fixed
Protocols 802.1x, DDNS, DHCP, FTP, HTTP, HTTPs, ICMP, IGMP, NTP, ONVIF, PPPoE, QoS, RTCP, RTP, RTSP, SMTP, SNMP, UDP, uPNP
Night Vision Yes
Programmable Yes
Field of View Horizontal, Vertical
Video Formats H.264, MJPEG
Output Voltage 12V DC
Maximum Aperture f/1.6
Motion Detection Yes
Night Vision Type Infrared
Maximum Frame Rate 30fps
Built-in Microphone Yes
Minimum Focal Length 2.8mm
Illumination Distance 100'
Connectivity Technology Wired
Effective Camera Resolution 4MP
Audio
Audio Encoding G.711
Memory Card Slot Yes
Camera
Image Sensor Type CMOS
Wide Dynamic Range Yes
Night Vision Distance 100 ft
Certifications
NDAA Compliant Yes
Ingress Protection Rating IP67
Display & Graphics
Image Sensor Size 1/3"
Maximum Video Resolution 1920 x 1080
Environmental Conditions
Operating Humidity 0-95% RH (Non-condensing)
Operating Temperature (T-T) -22-140°F
Maximum Operating Temperature 140°F (60°C)
Minimum Operating Temperature -22°F (-30°C)
Exposure
Minimum Illumination 0.0 lux (B/W), 0.005 lux (color)
Longest Shutter Speed 1/2 Second
Shortest Shutter Speed 1/100000 Second
Interfaces/Ports
Network (RJ-45) Yes
Lens
Focus Modes Auto, Manual
Focal Length 2.8mm
Lens Included Yes
Maximum Focal Length 2.8mm
Media & Performance
Network Technology 10 Base, 100 Base
Network & Communication
Remote Management Yes
Physical Characteristics
Color White
Weight 1.43 lb
Durability Dustproof, Impact Resistant, Vandal Resistant, Waterproof, Weather Resistant
Form Factor Dome
Power Description
Input Voltage 12V DC
Product Information
Mount Type Ceiling Mount, Junction Box Mount, Wall Mount
Storage
Storage Type Memory Card
Recording Formats 2K
TBD
Amperage 375mA
Video
Maximum Resolution 1280 x 720
Warranty
Limited Warranty 5-Year
Miscellaneous
Features 3D Digital Noise Reduction, Auto Flip, Auto Gain Control, Back Light Compensation (BLC), Day/Night, Highlight Compensation (HLC), Human Detection, Mirror, Noise Reduction, Privacy Masking, Removable IR Cut-off Filter, White Balance
Certifications CE, FCC, NDAA, ONVIF
Environmentally Friendly Yes
Impact Protection Rating IK10
Environmental Certification RoHS
