Digital Watchdog DWC-VSDG04MI MEGApix 4MP WDR Vandal Dome IP Camera with Smart IR, 2.8-12mm Varifocal Lens, White

SKU: DWC-VSDG04MI Digital Watchdog
Image of 6K-VSDG04MI
Product images for Digital Watchdog DWC-VSDG04MI MEGApix 4MP WDR Vandal Dome IP Camera with Smart IR, 2.8-12mm Varifocal Lens, White. 1 image(s) available. Click on image to view full size.
NDAA Compliant

Key Features

  • Deliver crisp, actionable footage with 4MP resolution at 30fps for reliable identification and evidence capture
  • Remote framing and focus using the 2.8–12mm motorized varifocal lens and autofocus to reduce on-site maintenance
  • Maintain continuous surveillance in challenging light with True WDR and Smart IR up to 164' for clear day/night monitoring
  • Minimize downtime and protect assets with IK10 vandal resistance and IP67 weatherproofing for outdoor and high-traffic areas
  • Reduce false alarms and streamline security operations with built-in analytics: line crossing, perimeter intrusion and tamper detection

Quick Specifications

Brand Name
Digital Watchdog
Manufacturer
Digital Watchdog
Product Line
MEGApix
Product Name
MEGApix 4MP vandal dome IP camera with a vari-focal lens and IR
View Full Technical Specifications

Frequently Bought Together

Product Information Tabs

Overview

Designed for professional security and surveillance deployments, the Digital Watchdog MEGApix DWC-VSDG04MI vandal dome IP camera delivers dependable, high-resolution monitoring where it matters most. This MEGApix 4MP dome camera captures smooth 30 fps video for clear identification and evidence-quality footage, while the 2.8–12mm motorized varifocal lens with autofocus lets you remotely dial in the perfect field of view without ladder work. True Wide Dynamic Range and Smart IR (effective to 164') ensure usable images in high-contrast scenes and low light, improving situational awareness across entrances, parking lots and perimeters. Built in an IK10 impact-resistant, IP67-rated aluminum housing, the camera stands up to vandalism and harsh weather, reducing service calls and lifecycle costs. ONVIF and NDAA compliance guarantee smooth integration into open-platform VMS and NVR systems, while edge analytics (line crossing, perimeter intrusion, tamper detection) lower false alarms and simplify monitoring workflows. Ideal for retail, education, transportation and critical infrastructure — contact your reseller to specify this Digital Watchdog vandal dome for your next security deployment.

Features

  • Deliver crisp, actionable footage with 4MP resolution at 30fps for reliable identification and evidence capture
  • Remote framing and focus using the 2.8–12mm motorized varifocal lens and autofocus to reduce on-site maintenance
  • Maintain continuous surveillance in challenging light with True WDR and Smart IR up to 164' for clear day/night monitoring
  • Minimize downtime and protect assets with IK10 vandal resistance and IP67 weatherproofing for outdoor and high-traffic areas
  • Reduce false alarms and streamline security operations with built-in analytics: line crossing, perimeter intrusion and tamper detection
General Information
Brand Name Digital Watchdog
Manufacturer Digital Watchdog
Product Line MEGApix
Product Name MEGApix 4MP vandal dome IP camera with a vari-focal lens and IR
Product Type Network Camera
Product Model DWC-VSDG04MI
Product Series V-Class
Manufacturer Part Number DWC-VSDG04MI
Supported Network Protocols IPv4, IPv6
Technical Information
Material Aluminum Die-cast
Lens Type Varifocal, Zoom
Protocols 802.1x, DDNS, DHCP, FTP, HTTP, HTTPs, ICMP, IGMP, NTP, ONVIF, PPPoE, QoS, RTCP, RTP, RTSP, SMTP, SNMP, UDP, uPNP
Night Vision Yes
Optical Zoom 4.3x
Programmable Yes
Field of View Horizontal, Vertical
Video Formats H.264, MJPEG
Output Voltage 12V DC
Maximum Aperture f/1.4
Motion Detection Yes
Night Vision Type Infrared
Maximum Frame Rate 30fps
Built-in Microphone Yes
Minimum Focal Length 2.8mm
Illumination Distance 164'
Connectivity Technology Wired
Effective Camera Resolution 4MP
Audio
Audio Encoding G.711
Memory Card Slot Yes
Camera
Image Sensor Type CMOS
Wide Dynamic Range Yes
Night Vision Distance 164 ft
Certifications
NDAA Compliant Yes
Ingress Protection Rating IP67
Display & Graphics
Image Sensor Size 1/3"
Maximum Video Resolution 1920 x 1080
Environmental Conditions
Operating Humidity 0-95% RH (Non-condensing)
Operating Temperature (T-T) -22-140°F
Maximum Operating Temperature 140°F (60°C)
Minimum Operating Temperature -22°F (-30°C)
Exposure
Minimum Illumination 0.0 lux (B/W), 0.005 lux (color)
Longest Shutter Speed 1/2 Second
Shortest Shutter Speed 1/100000 Second
Interfaces/Ports
Network (RJ-45) Yes
Lens
Focus Modes Auto, Manual
Focal Length 2.8-12mm
Lens Included Yes
Maximum Focal Length 12mm
Media & Performance
Network Technology 10 Base, 100 Base
Network & Communication
Remote Management Yes
Physical Characteristics
Color White
Weight 1.94 lb
Durability Weather Resistant
Form Factor Dome
Power Description
Input Voltage 12V DC
Product Information
Mount Type Ceiling Mount, Junction Box Mount, Wall Mount
Storage
Storage Type Memory Card
Recording Formats 2K
TBD
Amperage 625mA
Video
Maximum Resolution 1280 x 720
Warranty
Limited Warranty 5-Year
Miscellaneous
Features 3D Digital Noise Reduction, Auto Gain Control, Back Light Compensation (BLC), Cross Line Detection, Day/Night, Highlight Compensation (HLC), Human Detection, Noise Reduction, Smart IR, Tamper Detection, Tampering Alarm, White Balance
Certifications CE, FCC, NDAA, ONVIF
Country of Origin TW
Environmentally Friendly Yes
Impact Protection Rating IK10
Environmental Certification RoHS
