Digital Watchdog DWC-VSTB04BI MEGApix 4MP WDR Turret IP Camera with Smart IR, 2.8mm Fixed Lens, White
Key Features
- Capture actionable detail with 4MP resolution at 30fps for clear identification and smooth live monitoring
- 100' Smart IR and low-light sensitivity deliver reliable night surveillance without extra lighting
- True WDR balances bright and dark scenes so critical evidence is visible in challenging lighting
- Rugged IP67 and IK10-rated housing withstands weather and impact for dependable outdoor security
- ONVIF compatibility, dual streams and efficient codecs simplify VMS integration and bandwidth control
- 2.8mm fixed lens with 360° gimbal provides wide coverage and fast, flexible installation for ceilings or walls
Quick Specifications
- Brand Name
- Digital Watchdog
- Manufacturer
- Digital Watchdog
- Product Line
- MEGApix
- Product Name
- MEGApix 4MP turret IP camera with fixed lens and IR
Frequently Bought Together
Digital Watchdog DWC-VSTB04BI MEGApix 4MP WDR Turret IP Camera with Smart IR, 2.8mm Fixed Lens, White
$168.35
14 items selected
Total: $15,090.62
Product Information Tabs
Overview
Designed for professional security and surveillance deployments, the Digital Watchdog MEGApix DWC-VSTB04BI turret IP camera delivers crisp, dependable monitoring where it matters most. This MEGApix network camera captures 4MP video at 30fps using a 2.8mm fixed lens, making it easy to identify people and incidents across parking lots, building perimeters, and retail environments. True Wide Dynamic Range (WDR) ensures usable footage in high-contrast scenes while Smart IR extends clear night vision up to 100 feet without additional lighting. Built for real-world installations, the aluminum die-cast turret is IP67 weatherproof and IK10 impact resistant for reliable outdoor operation. IT-friendly features such as ONVIF conformance, dual streaming, multiple codecs and robust protocol support simplify integration with existing VMS and network infrastructure. Advanced analytics—line crossing, perimeter intrusion and tamper detection—help reduce false alarms and focus operator attention on threats. Backed by NDAA compliance and a 5-year limited warranty, this camera is a solid choice for enterprise-grade surveillance and monitoring. Add the MEGApix 4MP turret camera to your security system for proven performance and easy deployment.
Features
- Capture actionable detail with 4MP resolution at 30fps for clear identification and smooth live monitoring
- 100' Smart IR and low-light sensitivity deliver reliable night surveillance without extra lighting
- True WDR balances bright and dark scenes so critical evidence is visible in challenging lighting
- Rugged IP67 and IK10-rated housing withstands weather and impact for dependable outdoor security
- ONVIF compatibility, dual streams and efficient codecs simplify VMS integration and bandwidth control
- 2.8mm fixed lens with 360° gimbal provides wide coverage and fast, flexible installation for ceilings or walls
| General Information | |
|---|---|
| Brand Name | Digital Watchdog |
| Manufacturer | Digital Watchdog |
| Product Line | MEGApix |
| Product Name | MEGApix 4MP turret IP camera with fixed lens and IR |
| Product Type | Network Camera |
| Product Model | DWC-VSTB04BI |
| Product Series | V-Class |
| Manufacturer Part Number | DWC-VSTB04BI |
| Supported Network Protocols | IPv4, IPv6 |
| Technical Information | |
| Material | Aluminum Die-cast |
| Lens Type | Fixed |
| Protocols | 802.1x, DDNS, DHCP, FTP, HTTP, HTTPs, ICMP, IGMP, NTP, ONVIF, PPPoE, QoS, RTCP, RTP, RTSP, SMTP, SNMP, UDP, uPNP |
| Night Vision | Yes |
| Programmable | Yes |
| Field of View | Horizontal, Vertical |
| Video Formats | H.264, MJPEG |
| Output Voltage | 12V DC |
| Maximum Aperture | f/1.6 |
| Motion Detection | Yes |
| Night Vision Type | Infrared |
| Maximum Frame Rate | 30fps |
| Built-in Microphone | Yes |
| Minimum Focal Length | 2.8mm |
| Illumination Distance | 100' |
| Connectivity Technology | Wired |
| Effective Camera Resolution | 4MP |
| Audio | |
| Audio Encoding | G.711 |
| Memory Card Slot | Yes |
| Camera | |
| Image Sensor Type | CMOS |
| Wide Dynamic Range | Yes |
| Night Vision Distance | 100 ft |
| Certifications | |
| NDAA Compliant | Yes |
| Ingress Protection Rating | IP67 |
| Display & Graphics | |
| Image Sensor Size | 1/3" |
| Maximum Video Resolution | 1920 x 1080 |
| Environmental Conditions | |
| Operating Humidity | 0-95% RH (Non-condensing) |
| Operating Temperature (T-T) | -22-140°F |
| Maximum Operating Temperature | 140°F (60°C) |
| Minimum Operating Temperature | -22°F (-30°C) |
| Exposure | |
| Minimum Illumination | 0.0 lux (B/W), 0.005 lux (color) |
| Longest Shutter Speed | 1/2 Second |
| Shortest Shutter Speed | 1/100000 Second |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Lens | |
| Focus Modes | Auto, Manual |
| Focal Length | 2.8mm |
| Lens Included | Yes |
| Maximum Focal Length | 2.8mm |
| Media & Performance | |
| Network Technology | 10 Base, 100 Base |
| Network & Communication | |
| Remote Management | Yes |
| Physical Characteristics | |
| Color | White |
| Weight | 1.01 lb |
| Durability | Dustproof, Impact Resistant, Waterproof, Weather Resistant |
| Form Factor | Turret |
| Power Description | |
| Input Voltage | 12V DC |
| Product Information | |
| Mount Type | Ceiling Mount, Junction Box Mount, Wall Mount |
| Storage | |
| Storage Type | Memory Card |
| Recording Formats | 2K |
| TBD | |
| Amperage | 416.6mA |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Warranty | |
| Limited Warranty | 5-Year |
| Miscellaneous | |
| Features | Auto Gain Control, Automatic White Balance, Back Light Compensation (BLC), Cross Line Detection, Defog, Dual Stream, Dynamic Noise Reduction, Privacy Masking, Video Content Analytics, Wide Dynamic Range |
| Certifications | CE, FCC, NDAA, ONVIF |
| Country of Origin | TW |
| Environmentally Friendly | Yes |
| Impact Protection Rating | IK10 |
| Environmental Certification | RoHS |
