Digital Watchdog DW-BJCX4T-LX Blackjack CX 4K 16-Channel PoE NVR with Virtual Channels, 80 Mbps, Linux OS, 4TB HDD
Special Order Item
This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.
Key Features
- Rapid deployment with DW Spectrum optimization for plug-and-play surveillance and minimal configuration
- All-in-one PoE NVR delivers 16-channel monitoring with virtual channels to expand coverage without extra licenses
- Reliable Linux-based platform and NDAA/TAA compliance for secure, long-term enterprise use
- 4TB onboard storage and up to 80 Mbps recording throughput for continuous, high-quality footage retention
- Built-in DW Cloud access and real-time alerts for remote monitoring, mobile notifications, and proactive security response
- 15W-per-port PoE simplifies camera power and network setup, reducing installation time and costs
Quick Specifications
- Brand Name
- Digital Watchdog
- Manufacturer
- Digital Watchdog
- Product Line
- Blackjack
- Product Name
- Blackjack CX 16-channel embedded PoE NVR powered by DW Spectrum
Frequently Bought Together
Digital Watchdog DW-BJCX4T-LX Blackjack CX 4K 16-Channel PoE NVR with Virtual Channels, 80 Mbps, Linux OS, 4TB HDD
$3,228.12
13 items selected
Total: $11,883.17
Product Information Tabs
Overview
Secure enterprise sites quickly with the Digital Watchdog Blackjack CX 16-Channel PoE NVR — a DW Spectrum-optimized recorder built for reliable, scalable surveillance. This Blackjack CX network video recorder combines a stable Linux OS foundation with 4TB of onboard storage and 80 Mbps recording throughput to maintain crisp, continuous monitoring across up to 16 cameras. Virtual channel support and DW Spectrum integration let you expand monitoring capacity and manage devices centrally without complex licensing or extra hardware. PoE power on every port (15W) streamlines installations and reduces cabling, while NDAA/TAA compliance and lifetime DW Spectrum updates protect investments and satisfy procurement requirements. Remote access via DW Cloud, mobile apps, and real-time alerts make it easy to respond to incidents from any device, improving situational awareness and reducing response times. Ideal for retail, education, healthcare, and critical infrastructure, the Blackjack CX delivers dependable video security and simplified management for modern surveillance programs. Contact your reseller or add to cart to deploy enterprise-grade monitoring today.
Features
- Rapid deployment with DW Spectrum optimization for plug-and-play surveillance and minimal configuration
- All-in-one PoE NVR delivers 16-channel monitoring with virtual channels to expand coverage without extra licenses
- Reliable Linux-based platform and NDAA/TAA compliance for secure, long-term enterprise use
- 4TB onboard storage and up to 80 Mbps recording throughput for continuous, high-quality footage retention
- Built-in DW Cloud access and real-time alerts for remote monitoring, mobile notifications, and proactive security response
- 15W-per-port PoE simplifies camera power and network setup, reducing installation time and costs
| General Information | |
|---|---|
| Brand Name | Digital Watchdog |
| Manufacturer | Digital Watchdog |
| Product Line | Blackjack |
| Product Name | Blackjack CX 16-channel embedded PoE NVR powered by DW Spectrum |
| Product Type | Digital Video Recorder |
| Product Model | DW-BJCX4T-LX |
| Product Series | CX |
| Manufacturer Part Number | DW-BJCX4T-LX |
| Minimum Storage Drive Space | 4TB |
| Maximum Supported Storage Capacity | 4TB |
| Technical Information | |
| Bluetooth | No |
| Video Formats | H.264, MJPEG |
| Storage Capacity | 4TB |
| Power Consumption | 410W |
| Maximum Frame Rate | 30 fps |
| Number of Channels | 16 |
| Effective Camera Resolution | 8MP |
| Audio | |
| Recording Modes | Continuous, Motion detection, Motion Plus Low Res Always, Motion Plus Object, Motion Plus Object Plus Low Res, Object Only, Object Plus Low Res |
| Certifications | |
| TAA Compliant | Yes |
| Controllers | |
| RAID Levels | No RAID |
| Display & Graphics | |
| Maximum Video Resolution | 4096 x 2160 |
| Environmental Conditions | |
| Operating Humidity | 10-90% RH |
| Operating Temperature (T-T) | 32-104°F |
| Interfaces/Ports | |
| HDMI | No |
| Serial Port | Yes |
| Output Ports | DVI-I |
| Number of USB Ports | 1 |
| Number of Audio Line In | 1 |
| Number of Audio Line Out | 1 |
| Number of Ethernet Ports | 2 |
| License Information | |
| License Quantity | 4 |
| Network & Communication | |
| Ethernet | Yes |
| Remote Management | Yes |
| Ethernet Technology | 1 Gigabit Ethernet |
| Physical Characteristics | |
| Color | Black |
| Depth | 13.7" |
| Width | 16.29" |
| Height | 1.75" |
| Dimensions | 1.75†x 16.92†x 13.7†|
| Power Description | |
| PoE Budget | 15W |
| Input Voltage | 110-240V AC |
| Software | |
| Software Included | Yes |
| Storage | |
| Hard Drive Capacity | 4TB |
| Number of Hard Drives Supported | 2 |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Warranty | |
| Limited Warranty | 5-Year |
| Miscellaneous | |
| Compatibility | Blackjack NVRs (DW-BJ) |
| Certifications | CE, FCC, NDAA, ONVIF, TAA |
| Package Contents | Keyboard, Mouse |
| Country of Origin | TW |
| Environmentally Friendly | Yes |
| Environmental Certification | TAA |
