Digital Watchdog DWC-VSTB04BIB MEGApix 4MP Turret IP Camera with 2.8mm Fixed Lens, Black

SKU: DWC-VSTB04BIB Digital Watchdog
Image of 6K-DWCVST4BI
Product images for Digital Watchdog DWC-VSTB04BIB MEGApix 4MP Turret IP Camera with 2.8mm Fixed Lens, Black. 1 image(s) available. Click on image to view full size.

Key Features

  • Deliver crystal-clear, actionable 4MP video at 30 fps for improved identification and faster incident review
  • Rugged IP67 and IK10 aluminum turret housing ensures reliable outdoor surveillance in harsh environments
  • 100' Smart IR and low-light sensitivity (0.005 lux) provide dependable night monitoring without extra lighting
  • Built-in analytics (line crossing, perimeter intrusion, tamper detection) reduce false alarms and streamline security workflows
  • 2.8mm wide-angle lens plus 360° gimbal for fast, precise field-of-view adjustment and quicker installations

Quick Specifications

Brand Name
Digital Watchdog
Manufacturer
Digital Watchdog
Product Line
MEGApix
Product Name
MEGApix 4MP black turret IP camera with fixed lens and IR
View Full Technical Specifications

Frequently Bought Together

Product Information Tabs

Overview

Protect your property with high-resolution, reliable video designed for real-world security and monitoring needs. The Digital Watchdog MEGApix 4MP turret IP camera (DWC-VSTB04BIB) delivers crisp 4MP imagery at 30 fps and a 2.8mm fixed lens so operators capture identifying detail across entrances, lots, and perimeters. Built-in True WDR balances challenging lighting, while 100' Smart IR and 0.005 lux low-light performance maintain usable video around the clock.

Engineered for commercial deployments, the turret’s die-cast aluminum body carries IP67 weatherproof and IK10 impact ratings for long service life outdoors. Onboard analytics — line crossing, perimeter intrusion and tamper detection — reduce nuisance alerts and help security teams respond faster. Network-friendly H.264/MJPEG streaming, IPv4/IPv6 support and NDAA compliance make integration into modern NVR systems straightforward.

Ideal for retail, office campuses, parking facilities and perimeter monitoring, the DWC-VSTB04BIB combines durable hardware with smart surveillance features. Add this Digital Watchdog turret camera to your next security installation for dependable, high-detail monitoring and simplified event management.

Features

  • Deliver crystal-clear, actionable 4MP video at 30 fps for improved identification and faster incident review
  • Rugged IP67 and IK10 aluminum turret housing ensures reliable outdoor surveillance in harsh environments
  • 100' Smart IR and low-light sensitivity (0.005 lux) provide dependable night monitoring without extra lighting
  • Built-in analytics (line crossing, perimeter intrusion, tamper detection) reduce false alarms and streamline security workflows
  • 2.8mm wide-angle lens plus 360° gimbal for fast, precise field-of-view adjustment and quicker installations
General Information
Brand Name Digital Watchdog
Manufacturer Digital Watchdog
Product Line MEGApix
Product Name MEGApix 4MP black turret IP camera with fixed lens and IR
Product Type IP Turret Camera
Product Model DWC-VSTB04BIB
Product Series V-Class
Manufacturer Part Number DWC-VSTB04BIB
Supported Network Protocols IPv4, IPv6
Technical Information
Material Aluminum Die-cast
Lens Type Fixed
Protocols 802.1x, DDNS, DHCP, FTP, HTTP, HTTPs, ICMP, IGMP, NTP, PPPoE, QoS, RTCP, RTP, RTSP, SMTP, SNMP, UDP, uPNP
Night Vision Yes
Programmable Yes
Field of View Horizontal, Vertical
Video Formats H.264, MJPEG
Output Voltage 12V DC
Motion Detection Yes
Maximum Frame Rate 30fps
Built-in Microphone Yes
Illumination Distance 100'
Effective Camera Resolution 4MP
Audio
Audio Encoding G.711
Memory Card Slot Yes
Camera
Image Sensor Type CMOS
Wide Dynamic Range Yes
Certifications
Ingress Protection Rating IP67
Display & Graphics
Image Sensor Size 1/3"
Number of Sensors 1
Maximum Illumination 0.005 lux
Maximum Video Resolution 1920 x 1080
Environmental Conditions
Operating Humidity 0-95% RH (Non-condensing)
Operating Temperature (T-T) -22-140°F
Maximum Operating Temperature 140°F
Minimum Operating Temperature -22°F
Exposure
Minimum Illumination 0.0 lux (B/W), 0.005 lux (color)
Longest Shutter Speed 1/100000
Shortest Shutter Speed 1/30 s
Lens
Focus Modes Auto, Manual
Focal Length 2.8mm
Lens Included Yes
Media & Performance
Network Technology 10 Base, 100 Base
Physical Characteristics
Color Black
Depth 3.77"
Width 4.25"
Weight 1.01 lb
Durability Weather Resistant
Form Factor Turret
TBD
Amperage 416.6mA
Warranty
Limited Warranty 5-Year
Miscellaneous
Certifications CE, FCC, NDAA
Impact Protection Rating IK10
Environmental Certification FC
