Fire-Lite ES-200X Addressable Fire Alarm Control Panel, 198-Point (Replaces MS9200UDLS)
Image of 1
Key Features
- Faster installs and lower labor costs with auto-programming, integrated annunciator, and a quick-install chassis
- Dual-path IP/POTS communicator reduces monthly phone line expense while ensuring reliable central-station monitoring
- Scales to 198 addressable devices (99 detectors + 99 modules) to cover medium and large commercial sites
- USB and Ethernet upload/download of programming, history and walk-test data for secure remote maintenance and compliance
- Flexible notification control with two built-in, independently programmable Class A/Style Z or Class B/Style Y NACs and programmable function keys
Quick Specifications
- Product Model
- ES-200X
- Brand Name
- Fire-Lite Alarms by Honeywell
- Product Line
- Endurance
- Product Name
- ES-200X Intelligent Addressable FACP with Communicator
Frequently Bought Together
Fire-Lite ES-200X Addressable Fire Alarm Control Panel, 198-Point (Replaces MS9200UDLS)
$1,447.25
3 items selected
Total: $5,724.59
Explore the details
Product information
ES-200X
Overview
Deliver dependable, scalable fire protection for commercial and institutional sites with the Fire-Lite Alarms by Honeywell ES-200X addressable fire alarm control panel. Designed to simplify installation and ongoing service, the ES-200X supports up to 198 addressable devices (99 detectors and 99 modules) and includes a pre-installed IPOTS-COM dual communicator (POTS + IP) to cut recurring line costs while maintaining robust central-station monitoring and security reporting. The panel's built-in LCD annunciator, auto-programming (learn mode) and quick-install chassis speed deployments, and USB/Ethernet upload-download capability enables fast remote programming, firmware updates and log retrieval—reducing site visits and downtime. Two independently programmable NAC circuits (Style Z/Class A or Style Y/Class B) and support for addressable sounder bases deliver flexible notification and integration with broader security and surveillance systems. Backed by a 3-year limited warranty and US manufacturing, the ES-200X is ideal for multi-tenant, education, healthcare and commercial installations that need reliable monitoring and easy maintenance. Contact us to specify or order the ES-200X for your next fire protection project.
Features
- Faster installs and lower labor costs with auto-programming, integrated annunciator, and a quick-install chassis
- Dual-path IP/POTS communicator reduces monthly phone line expense while ensuring reliable central-station monitoring
- Scales to 198 addressable devices (99 detectors + 99 modules) to cover medium and large commercial sites
- USB and Ethernet upload/download of programming, history and walk-test data for secure remote maintenance and compliance
- Flexible notification control with two built-in, independently programmable Class A/Style Z or Class B/Style Y NACs and programmable function keys
| General Information | |
|---|---|
| Brand Name | Fire-Lite Alarms by Honeywell |
| Manufacturer | Honeywell International, Inc |
| Product Line | Endurance |
| Product Name | ES-200X Intelligent Addressable FACP with Communicator |
| Product Type | Fire Alarm Control/Communicator |
| Product Model | ES-200X |
| Product Series | ES-200X |
| Country of Origin | US |
| Manufacturer Part Number | ES-200X |
| Technical Information | |
| Panel Control Type | Addressable |
| Number of Events Log | 1000 |
| Connectivity Technology | Wired |
| Number of Relays Supported | 2 |
| Battery Information | |
| Battery Voltage | 12.00V |
| Battery Chemistry | Lead acid |
| Display & Graphics | |
| Display Type | Non-Touchscreen |
| Power Description | |
| Input Voltage | 120V AC, 230V AC |
| Product Replacements & Other Alternatives | |
| Model Number Replaces | MS-9200UDLS |
| Warranty | |
| Limited Warranty | 3-Year |
