Fire-Lite MS-10UD-7 10-Zone, 24V Fire Alarm Control Panel with Backbox and FLPS-7 Power Supply
Image of 1
Key Features
- Quick, on-site setup with built-in 80-character LCD and keypad — reduces installation time and eliminates the need for external programmers
- Reliable remote monitoring via integrated two-line DACT for immediate off‑premises alarm reporting and central station connectivity
- Flexible zoning and circuit options: 10 conventional zones (Style B) or convertible to 5 zones Style D with optional modules, letting you scale to building needs
- Robust notification support with four NAC circuits and 7.0 A total usable current to power horns, strobes and auxiliary devices for code-compliant notification
- NAC synchronization and broad device compatibility (System Sensor, Wheelock, Gentex, Faraday, Amseco) for seamless integration with existing security and life-safety equipment
- Expandable annunciation and relay options — support remote annunciators, printer gateways and programmable relays for centralized monitoring and facility integration
Quick Specifications
- Product Model
- MS-10UD-7
- Brand Name
- Fire-Lite Alarms by Honeywell
- Product Name
- MS-10UD-7 Burglar Alarm Control/Communicator
- Product Type
- Fire Alarm Control/Communicator
Frequently Bought Together
Fire-Lite MS-10UD-7 10-Zone, 24V Fire Alarm Control Panel with Backbox and FLPS-7 Power Supply
$1,496.51
6 items selected
Total: $3,675.76
Explore the details
Product information
MS-10UD-7
Overview
Deliver centralized, code-compliant fire detection and fast off‑site alarm reporting for small to mid-size commercial sites. The Fire-Lite Alarms by Honeywell MS-10UD-7 fire alarm control panel combines user-friendly programming and robust monitoring features so facilities managers and integrators can deploy reliable protection with minimal downtime. The panel supports 10 conventional zones and includes a built-in two-line DACT for central station monitoring, while an integral 80-character backlit LCD keypad simplifies commissioning and daily operation. With four NAC circuits and 7.0 amps of usable notification power, the MS-10UD-7 reliably supports horns, strobes and synchronized notification appliances across offices, retail, education and light industrial environments. Native support for NAC synchronization and a broad annunciator bus allow easy integration with security, surveillance and building automation systems. For installers needing flexibility, the platform accepts optional relay, printer and remote annunciator modules to tailor reporting and control. Specify the MS-10UD-7 for dependable fire alarm monitoring and streamlined installation — contact us to configure or add to your next project.
Features
- Quick, on-site setup with built-in 80-character LCD and keypad — reduces installation time and eliminates the need for external programmers
- Reliable remote monitoring via integrated two-line DACT for immediate off‑premises alarm reporting and central station connectivity
- Flexible zoning and circuit options: 10 conventional zones (Style B) or convertible to 5 zones Style D with optional modules, letting you scale to building needs
- Robust notification support with four NAC circuits and 7.0 A total usable current to power horns, strobes and auxiliary devices for code-compliant notification
- NAC synchronization and broad device compatibility (System Sensor, Wheelock, Gentex, Faraday, Amseco) for seamless integration with existing security and life-safety equipment
- Expandable annunciation and relay options — support remote annunciators, printer gateways and programmable relays for centralized monitoring and facility integration
| General Information | |
|---|---|
| Brand Name | Fire-Lite Alarms by Honeywell |
| Manufacturer | Honeywell International, Inc |
| Product Name | MS-10UD-7 Burglar Alarm Control/Communicator |
| Product Type | Fire Alarm Control/Communicator |
| Product Model | MS-10UD-7 |
| Product Series | MS |
| Country of Origin | US |
| Manufacturer Part Number | MS-10UD-7 |
| Technical Information | |
| Panel Control Type | Conventional |
| Connectivity Technology | Wired |
| Number of Standard Zones | 10 |
| Number of Relays Supported | 3 |
| Physical Characteristics | |
| Depth | 41.66cm |
| Height | 19.26" |
| Power Description | |
| Input Voltage | 120V AC |
| Product Replacements & Other Alternatives | |
| Model Number Replaces | MS-4 |
