Evolution EV4K2004 4K HDMI Extender over Single Coax Cable with Bi-directional IR
Image of 9
Key Features
- Send pristine 4K60 HDR video over existing RG6 coax to save on rewiring and installation costs
- Preserves image quality with HDMI 2.0/HDCP 2.2 support and 4:4:4 chroma for critical security and surveillance feeds
- Bi-directional IR pass-through (20–60 KHz) lets operators control sources or displays from a remote location
- Long-distance transmission: up to 330' (100m) for 4K60 and up to 230' (70m) with HDR10 over a single coax cable
- Compact, wall-mount design and auto equalization simplify installation in control rooms, monitoring stations, and digital signage deployments
Quick Specifications
- Product Model
- EV4K2004
- Brand Name
- Evolution by Vanco
- Product Line
- Evolution
- Product Name
- 4K HDMI® over Single Coax Cable with Bi-directional IR
Frequently Bought Together
Evolution EV4K2004 4K HDMI Extender over Single Coax Cable with Bi-directional IR
$785.33
4 items selected
Total: $2,411.59
Explore the details
Product information
EV4K2004
Overview
The Evolution by Vanco EV4K2004 HDMI extender converts a single RG6 coax into a reliable long‑reach link for 4K AV and security systems, letting integrators reuse existing cabling to cut labor and material costs. This HDMI extender supports up to 4K at 60 Hz with 4:4:4 chroma and HDR10, while maintaining HDMI 2.0 and HDCP 2.2 compliance so surveillance, monitoring and broadcast-quality signage retain full color fidelity and copy protection. Auto signal equalization and dynamic EDID remove guesswork at install, and uncompressed digital audio keeps voice and alarm channels accurate. Bi-directional IR (20–60 kHz) enables remote control of sources or displays from the monitor side, ideal for control rooms, security consoles, or distributed AV systems. Housed in a compact, wall-mount chassis with a 10-year limited warranty, the EV4K2004 is built for long-term commercial deployments. Specify the EV4K2004 for security, surveillance, digital signage, and remote monitoring projects — contact your Evolution by Vanco dealer to integrate it into your next installation.
Features
- Send pristine 4K60 HDR video over existing RG6 coax to save on rewiring and installation costs
- Preserves image quality with HDMI 2.0/HDCP 2.2 support and 4:4:4 chroma for critical security and surveillance feeds
- Bi-directional IR pass-through (20–60 KHz) lets operators control sources or displays from a remote location
- Long-distance transmission: up to 330' (100m) for 4K60 and up to 230' (70m) with HDR10 over a single coax cable
- Compact, wall-mount design and auto equalization simplify installation in control rooms, monitoring stations, and digital signage deployments
| General Information | |
|---|---|
| Brand Name | Evolution by Vanco |
| Manufacturer | Vanco International, Inc |
| Product Line | Evolution |
| Product Name | 4K HDMI® over Single Coax Cable with Bi-directional IR |
| Product Type | Video Extender Transmitter/Receiver |
| Product Model | EV4K2004 |
| Country of Origin | TW |
| Manufacturer Part Number | EV4K2004 |
| Technical Information | |
| Media Type Supported | Coaxial |
| Connectivity Technology | Wired |
| Maximum Operating Distance | 328' |
| Number of Input Devices Supported | 1 |
| Number of Output Devices Supported | 1 |
| Certifications | |
| TAA Compliant | Yes |
| Display & Graphics | |
| Maximum Video Resolution | 4096 x 2160 |
| Interfaces/Ports | |
| Number of HDMI Inputs | 1 |
| Number of HDMI Outputs | 1 |
| Physical Characteristics | |
| Color | Black |
| Width | 3.70" |
| Height | 1.00" |
| Dimensions | 3.5" x 3.7" x 1" |
| Product Information | |
| Length | 3.50" |
| Mount Type | Wall Mount |
| Product Replacements & Other Alternatives | |
| Model Number Replaces | EVEX2004 |
| Video | |
| Graphics Mode | 4K UHD |
| Warranty | |
| Limited Warranty | 2-Year |
