Hanwha PNM-8082VT P-Series 2MP 3-Channel Multi-Directional Camera, 3-6mm Varifocal Lenses, White
Key Features
- Maximize coverage and reduce blind spots with three 2MP sensors (6MP total) that deliver multi-directional surveillance from a single IP address.
- Simplify installation and networking with PoE+ support and a single-stream setup, lowering wiring costs and integration time for enterprise deployments.
- Maintain clear imagery in challenging scenes with 150dB WDR and true day/night performance for reliable identification and monitoring.
- Cut bandwidth and storage needs with WiseStream II and H.265 compression while preserving critical detail at 30 fps.
- Rugged outdoor design (IP66/IK10, -40° to 55°C) ensures continuous operation in harsh environments, backed by dual microSD slots for local failover recording.
- Built-in analytics (tamper, motion, loitering, directional detection) enable smarter event filtering and faster incident response.
Quick Specifications
- Product Model
- PNM-8082VT
- Brand Name
- Hanwha Vision
- Product Name
- 6MP (2MP x 3) Multi-Sensor, Multi-Directional Camera
- Product Type
- Network Camera
Frequently Bought Together
Hanwha PNM-8082VT P-Series 2MP 3-Channel Multi-Directional Camera, 3-6mm Varifocal Lenses, White
$1,040.40
10 items selected
Total: $2,704.35
Product Information Tabs
Overview
Designed for perimeter and area monitoring where comprehensive coverage and rugged reliability matter, the Hanwha Vision PNM-8082VT P-Series multi-directional camera delivers continuous, actionable surveillance with minimal infrastructure overhead. This panoramic network camera combines three 2MP sensors (6MP total) with motorized 3–6mm varifocal lenses to cover wide fields of view and minimize blind spots using a single IP address. Built for real-world security, the PNM-8082VT supports PoE+ for simplified deployment, WiseStream II with H.265 to reduce bandwidth and storage, and 150dB WDR plus true day/night imaging for clear identification in high-contrast scenes. IP66 and IK10 ratings, wide operating temperatures, and dual microSD slots provide dependable outdoor performance and local failover recording. Onboard analytics—motion, tamper, loitering and directional detection—help teams prioritize events and accelerate incident response. Ideal for campuses, transportation hubs, and critical infrastructure monitoring, this Hanwha multi-sensor panoramic camera provides scalable, high-quality surveillance with lower total cost of ownership. Contact sales to specify mounting options or add the PNM-8082VT to your next security deployment.
Features
- Maximize coverage and reduce blind spots with three 2MP sensors (6MP total) that deliver multi-directional surveillance from a single IP address.
- Simplify installation and networking with PoE+ support and a single-stream setup, lowering wiring costs and integration time for enterprise deployments.
- Maintain clear imagery in challenging scenes with 150dB WDR and true day/night performance for reliable identification and monitoring.
- Cut bandwidth and storage needs with WiseStream II and H.265 compression while preserving critical detail at 30 fps.
- Rugged outdoor design (IP66/IK10, -40° to 55°C) ensures continuous operation in harsh environments, backed by dual microSD slots for local failover recording.
- Built-in analytics (tamper, motion, loitering, directional detection) enable smarter event filtering and faster incident response.
| General Information | |
|---|---|
| Brand Name | Hanwha Vision |
| Manufacturer | Hanwha Group |
| Product Name | 6MP (2MP x 3) Multi-Sensor, Multi-Directional Camera |
| Product Type | Network Camera |
| Product Model | PNM-8082VT |
| Product Series | P |
| Manufacturer Part Number | PNM-8082VT |
| Technical Information | |
| Lens Type | Varifocal |
| Optical Zoom | 2x |
| Field of View | Diagonal, Horizontal, Vertical |
| Video Formats | H.264, H.265, MJPEG |
| Maximum Aperture | f/3.1 |
| Maximum Frame Rate | 30fps |
| Minimum Focal Length | 3mm |
| Connectivity Technology | Wired |
| Field of View (Vertical) | 57° |
| Field of View (Horizontal) | 107° |
| Effective Camera Resolution | 2MP |
| Camera | |
| Image Sensor Type | CMOS |
| Wide Dynamic Range | Yes |
| Certifications | |
| NDAA Compliant | Yes |
| Ingress Protection Rating | IP66 |
| Display & Graphics | |
| Number of Sensors | 3 |
| Maximum Video Resolution | 1600 x 1200 |
| Environmental Conditions | |
| Operating Humidity | 0.95 |
| Maximum Operating Temperature | 131°F (55°C) |
| Minimum Operating Temperature | -40°F (-40°C) |
| Exposure | |
| Longest Shutter Speed | 2 Second |
| Shortest Shutter Speed | 1/12000 Second |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Lens | |
| Focal Length | 3-6mm |
| Lens Included | Yes |
| Minimum Aperture | f/2.2 |
| Maximum Focal Length | 6mm |
| Network & Communication | |
| Remote Management | Yes |
| Physical Characteristics | |
| Color | White |
| Width | 10" |
| Height | 5" |
| Weight | 6.61lb |
| Durability | Dustproof, Impact Resistant, Waterproof |
| Form Factor | Dome |
| Product Information | |
| Diameter | 9.9" |
| Mount Type | Backbox Mount, Box Mount, Ceiling Mount, Corner Mount, Gang Box Mount, Pendant Mount, Pole Mount, Roof Mount, Wall Mount |
| Storage | |
| Recording Formats | Full HD |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Analog Video Signal Format | CVBS |
| Miscellaneous | |
| Features | Alarm Triggering, Automatic White Balance, Back Light Compensation (BLC), Defog, Digital Image Stabilization, Digital Noise Reduction, Highlight Compensation (HLC), Motion Detection, Privacy Masking, Tamper Detection |
| Indoor/Outdoor | Outdoor |
| Country of Origin | KR |
| Impact Protection Rating | IK10 |
