Hanwha PNM-9002VQ P-Series x 5MP 4-Channel Multi-Directional Camera, Lenses Not Included, White

SKU: PNM-9002VQ Hanwha Vision
Hanwha PNM-9002VQ WiseNet P-Series 2-5MP 4-Channel Multi-Directional Camera, Lenses Not Included
Product images for Hanwha PNM-9002VQ P-Series x 5MP 4-Channel Multi-Directional Camera, Lenses Not Included, White. 1 image(s) available. Click on image to view full size.
NDAA Compliant TAA Compliant

Key Features

  • Maximize coverage with a single Hanwha multi-directional camera that replaces multiple fixed cameras, reducing installation and maintenance costs
  • Flexible lens module system lets you tailor each of the four sensors to surveillance needs (2MP or 5MP modules), ideal for mixed scenes
  • Intelligent compression (WiseStream II and H.265) lowers bandwidth and storage while preserving image detail for long-term monitoring
  • Rugged IP66 / IK10 housing and -40°F to 131°F operation ensure reliable outdoor performance in harsh industrial and public environments
  • On-board analytics and four SD card slots enable edge recording, smart alerts, and remote management for faster incident response

Quick Specifications

Product Model
PNM-9002VQ
Brand Name
Hanwha Vision
Product Name
4x 2MP / 5MP Multi-sensor Multi-directional Camera
Product Type
Network Camera
View Full Technical Specifications

Frequently Bought Together

Explore the details

Product information

PNM-9002VQ

Overview

Deliver comprehensive, reliable surveillance with the Hanwha Vision PNM-9002VQ P-Series 4-channel multi-directional camera. Designed for wide-area monitoring of campuses, transportation hubs, retail centers and critical infrastructure, this network camera consolidates coverage so you need fewer devices and less infrastructure. Configure each of the four interchangeable lens modules (2MP or 5MP) to balance resolution and field of view — combined imaging can reach up to 20MP depending on modules — and capture smooth video up to 60 fps (2MP) or 30 fps (5MP). Advanced features like WiseStream II and H.265 reduce bandwidth and storage costs without compromising clarity, while WDR (up to 150 dB with 2MP modules) preserves detail in challenging lighting. Built for demanding deployments, the PNM-9002VQ includes IP66/IK10 protection, four SD card slots for edge recording, and support for video analytics and remote management. Note: lens modules are required but not included, giving you flexibility to specify focal lengths per site. Configure your lenses and upgrade your security monitoring — contact us to design the right multi-directional surveillance solution.

Features

  • Maximize coverage with a single Hanwha multi-directional camera that replaces multiple fixed cameras, reducing installation and maintenance costs
  • Flexible lens module system lets you tailor each of the four sensors to surveillance needs (2MP or 5MP modules), ideal for mixed scenes
  • Intelligent compression (WiseStream II and H.265) lowers bandwidth and storage while preserving image detail for long-term monitoring
  • Rugged IP66 / IK10 housing and -40°F to 131°F operation ensure reliable outdoor performance in harsh industrial and public environments
  • On-board analytics and four SD card slots enable edge recording, smart alerts, and remote management for faster incident response
40 of 40 specifications
Technical specifications for Hanwha PNM-9002VQ P-Series x 5MP 4-Channel Multi-Directional Camera, Lenses Not Included, White
General Information
Brand Name Hanwha Vision
Manufacturer Hanwha Group
Product Name 4x 2MP / 5MP Multi-sensor Multi-directional Camera
Product Type Network Camera
Product Model PNM-9002VQ
Product Series P
Manufacturer Part Number PNM-9002VQ
Technical Information
Lens Type Fixed
Video Formats H.264, H.265, MJPEG
Maximum Frame Rate 60fps
Connectivity Technology Wired
Effective Camera Resolution 5MP
Camera
Wide Dynamic Range Yes
Certifications
TAA Compliant Yes
NDAA Compliant Yes
Ingress Protection Rating IP66
Display & Graphics
Number of Sensors 4
Maximum Video Resolution 1600 x 1200
Environmental Conditions
Operating Humidity 0.9
Maximum Operating Temperature 131°F (55°C)
Minimum Operating Temperature -40°F (-40°C)
Exposure
Longest Shutter Speed 2 Second
Shortest Shutter Speed 1/12000 Second
Interfaces/Ports
Network (RJ-45) Yes
Lens
Lens Included No
Network & Communication
Remote Management Yes
Others
Model Number Replaces PNM-9000VQ
Physical Characteristics
Color White
Weight 6.61lb
Durability Dustproof, Impact Resistant, Waterproof
Form Factor Dome
Product Information
Diameter 10"
Mount Type Box Mount, Ceiling Mount, Corner Mount, Flush Mount, Gooseneck Mount, Pendant Mount, Pole Mount, Wall Mount
Storage
Storage Type Memory Card
Video
Maximum Resolution 1280 x 720
Analog Video Signal Format CVBS
Warranty
Limited Warranty 3-Year
Miscellaneous
Features Alarm Triggering, Automatic White Balance, Back Light Compensation (BLC), Day/Night, Defog, Digital Noise Reduction, Enter/Exit Detector, Face Detection, Highlight Compensation (HLC), Motion Detection, Privacy Masking, Wide Dynamic Range
Country of Origin KR
Impact Protection Rating IK10
