Potter S-24WR S-24 Series 24V DC Selectable Candela, Low Profile Evacuation Strobe, Red
Image of 1
Key Features
- Ultra-low current draw reduces power and wiring costs for large fire and security systems
- Field-selectable candela (15, 30, 60, 75, 110) lets you tailor light output for code and site needs
- Low-profile, tamperproof design blends into installations while resisting unauthorized access
- Super-Slide® mounting plate and Checkmate® instant voltage verification speed installation and commissioning
- Synchronization capability with AVSM modules for coordinated visual alerts across facilities
- UL 464 / UL 1971 listed with a 3-year warranty for dependable, code-compliant evacuation signaling
Quick Specifications
- Product Model
- S-24WR
- Brand Name
- Potter Electric Signal, LLC
- Product Name
- S-24 S-24WR Security Strobe Light
- Product Type
- Security Strobe Light
Frequently Bought Together
Potter S-24WR S-24 Series 24V DC Selectable Candela, Low Profile Evacuation Strobe, Red
$50.83
6 items selected
Total: $622.64
Explore the details
Product information
S-24WR
Overview
Deliver reliable, code-compliant evacuation signaling without compromising installation speed or energy efficiency. The Potter S-24WR low-profile evacuation strobe from Potter Electric Signal is a 24V DC visual appliance designed for fire alarm, security and monitoring systems where dependable notification and low operating cost matter. With field-selectable candela options (15, 30, 60, 75 and 110 cd) and a minimum 1 Hz flash rate, you can match light output to room size and application while maintaining minimal current draw. Installers benefit from the Super-Slide® mounting plate and Checkmate® instant voltage verification to prewire, test supervision and commission faster. The tamperproof grille and compact red housing provide discreet, secure coverage for surveillance, security and life-safety deployments. UL 464 and UL 1971 listings and a three-year warranty give contractors and facility managers the confidence to specify this strobe for schools, commercial buildings, healthcare and industrial sites. For a reliable, energy-efficient visual notification solution that integrates with existing fire and security systems, choose the Potter S-24WR — contact your distributor or order today.
Features
- Ultra-low current draw reduces power and wiring costs for large fire and security systems
- Field-selectable candela (15, 30, 60, 75, 110) lets you tailor light output for code and site needs
- Low-profile, tamperproof design blends into installations while resisting unauthorized access
- Super-Slide® mounting plate and Checkmate® instant voltage verification speed installation and commissioning
- Synchronization capability with AVSM modules for coordinated visual alerts across facilities
- UL 464 / UL 1971 listed with a 3-year warranty for dependable, code-compliant evacuation signaling
| General Information | |
|---|---|
| Brand Name | Potter Electric Signal, LLC |
| Manufacturer | Potter Electric Signal, LLC |
| Product Name | S-24 S-24WR Security Strobe Light |
| Product Type | Security Strobe Light |
| Product Model | S-24WR |
| Product Series | S-24 |
| Manufacturer Part Number | S-24WR |
| Technical Information | |
| Alarm Type | Visual |
| Application/Usage | Evacuation, Fire |
| Connectivity Technology | Wired |
| Physical Characteristics | |
| Color | Red |
| Depth | 2.5" |
| Width | 4.5" |
| Height | 5" |
| Durability | Tamperproof |
| Lens Color | Clear |
| Form Factor | Box Mount, Bracket Mount, Wall Mount |
| Power Description | |
| Power Source | DC |
| Input Voltage | 24V DC |
| Product Information | |
| Mount Type | Box Mount, Bracket Mount, Wall Mount |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Country of Origin | US |
