AtlasIED SM52T-B 5.25" 2-Way All-Weather Speaker with 30W 70V, 100V Transformer Pair, Black

SKU: SM52T-B AtlasIED
Atlas Sound Strategy SM52T 2-way Indoor/Outdoor Surface Mount Speaker - 100 W RMS - Black
Product images for AtlasIED SM52T-B 5.25" 2-Way All-Weather Speaker with 30W 70V, 100V Transformer Pair, Black. 1 image(s) available. Click on image to view full size.
NDAA Compliant

Key Features

  • Reliable all-weather construction delivers consistent audio for outdoor paging, monitoring and security applications
  • Integrated 30W 70V/100V transformer pair simplifies distributed audio and paging system installation
  • Compact 5.25" 2-way design with 90 dB sensitivity provides clear voice intelligibility and music fidelity in small-to-medium spaces
  • TRX WaveGuide and FerroFluid-cooled titanium tweeter ensure even 90° x 90° coverage for stable surveillance/announcement zones
  • PolyGuard tweeter protection and heavy-duty mounting hardware reduce downtime and maintenance in high-use commercial environments

Quick Specifications

Product Model
SM52T
Brand Name
AtlasIED
Product Line
Strategy
Product Name
Strategy Surface Mount Loudspeaker System
View Full Technical Specifications

Explore the details

Product information

SM52T-B

Overview

Built for dependable voice reproduction in security, paging and outdoor monitoring, the AtlasIED SM52T-B is a compact 5.25" 2-way all-weather pro speaker engineered for commercial and surveillance installations. The SM52T-B combines a sensitive woofer and FerroFluid-cooled titanium dome tweeter with AtlasIED's TRX WaveGuide for smooth, even 90° x 90° coverage—so messages remain intelligible across plazas, lobbies and perimeter monitoring zones.

This black surface-mount speaker ships as a pair and includes a 30W 70V/100V transformer pair for fast integration into distributed audio or paging systems, while the 8 Ω impedance and 90 dB sensitivity deliver efficient output with less amplifier power. Weather-resistant polypropylene construction, powder-coated grilles and PolyGuard protection reduce maintenance and extend service life in outdoor and security-focused deployments. Backed by a five-year warranty and heavy-duty mounting bracket, the SM52T-B is ideal for retail, campus, transit and critical infrastructure where reliable announcements and monitoring are essential. Add the AtlasIED SM52T-B to your next security or public address design for clear, durable sound—order a pair today.

Features

  • Reliable all-weather construction delivers consistent audio for outdoor paging, monitoring and security applications
  • Integrated 30W 70V/100V transformer pair simplifies distributed audio and paging system installation
  • Compact 5.25" 2-way design with 90 dB sensitivity provides clear voice intelligibility and music fidelity in small-to-medium spaces
  • TRX WaveGuide and FerroFluid-cooled titanium tweeter ensure even 90° x 90° coverage for stable surveillance/announcement zones
  • PolyGuard tweeter protection and heavy-duty mounting hardware reduce downtime and maintenance in high-use commercial environments
30 of 30 specifications
Technical specifications for AtlasIED SM52T-B 5.25" 2-Way All-Weather Speaker with 30W 70V, 100V Transformer Pair, Black
General Information
Brand Name AtlasIED
Manufacturer AtlasIED
Product Line Strategy
Product Name Strategy Surface Mount Loudspeaker System
Product Type Speaker
Product Model SM52T
Product Series SM
Packaged Quantity 2
Manufacturer Part Number SM52TB
Technical Information
Material Aluminum, Brass, Ferrofluid, Injection Molded Polypropylene (IMPP), Rubber, Titanium, Zinc Plated
Impedance 8 ohms
Sensitivity 90dB
Speaker Size 5"
Crossover Type 2-way
Application/Usage Commercial, Professional, Residential
Audio
RMS Output Power 100W
Number of Speakers 1
Maximum Frequency Response 20 kHz
Minimum Frequency Response 85Hz
Certifications
TAA Compliant No
NDAA Compliant Yes
Physical Characteristics
Size 5.25"
Color Black
Depth 5.87"
Width 6.9"
Height 10.2"
Durability Weather Resistant
Product Information
Mount Type Surface Mount
Warranty
Limited Warranty 5-Year
Miscellaneous
Indoor/Outdoor Indoor
