TP-Link TL-SF1009P 9-Port 10/100Mbps Desktop Switch with 8-Port PoE+

SKU: TL-SF1009P TP-Link
TP-Link TL-SF1009P 9-Port 10/100Mbps Desktop Switch with 8-Port PoE+
Product images for TP-Link TL-SF1009P 9-Port 10/100Mbps Desktop Switch with 8-Port PoE+. 10 image(s) available. Click on image to view full size.

Key Features

  • Deliver reliable power and data to IP cameras and access points with 8 PoE+ ports, simplifying surveillance and Wi‑Fi deployments
  • 65W total PoE budget and up to 30W per port to support high‑power devices without extra cabling or injectors
  • Plug-and-play 9‑port 10/100Mbps desktop switch for fast, no‑config installations in offices, dorms, and retail sites
  • Extend Mode lets PoE reach up to 250m at 10Mbps, enabling flexible camera placement beyond standard cable limits
  • Priority and Isolation Modes protect video/voice traffic and separate client streams for improved performance and security
  • Compact metal desktop design with sturdy build and a 3‑year warranty for dependable, low‑maintenance operation

Quick Specifications

Product Model
TL-SF1009P
Brand Name
TP-Link
Product Name
9-Port 10/100Mbps Desktop Switch with 8-Port PoE+
Product Type
Switch
View Full Technical Specifications

Product Information Tabs

Overview

Designed for streamlined security and network edge deployments, the TP-Link TL-SF1009P 9‑Port 10/100Mbps Desktop Switch with 8‑Port PoE+ delivers dependable power and connectivity for surveillance, monitoring, and wireless access. This TP-Link unmanaged switch powers IP cameras, access points and VoIP phones with eight IEEE 802.3af/at PoE+ ports—up to 30W per port and a 65W total PoE budget—eliminating the need for separate power supplies. Its plug-and-play design and compact metal housing let technicians install a secure, clutter‑free network quickly while Extend Mode supports PoE transmission up to 250 meters for flexible camera placement. Built‑in Priority Mode ensures ports 1–2 get precedence for mission‑critical video or voice streams, while Isolation Mode segments client traffic to reduce lateral access and improve performance. With 9 total 10/100Base‑T ports, RoHS compliance and a 3‑year warranty, the TL-SF1009P is ideal for small businesses, remote offices, and multi‑unit residential sites needing reliable security and monitoring infrastructure. Add it to your next surveillance or networking project to simplify deployment and ensure continuous operation.

Features

  • Deliver reliable power and data to IP cameras and access points with 8 PoE+ ports, simplifying surveillance and Wi‑Fi deployments
  • 65W total PoE budget and up to 30W per port to support high‑power devices without extra cabling or injectors
  • Plug-and-play 9‑port 10/100Mbps desktop switch for fast, no‑config installations in offices, dorms, and retail sites
  • Extend Mode lets PoE reach up to 250m at 10Mbps, enabling flexible camera placement beyond standard cable limits
  • Priority and Isolation Modes protect video/voice traffic and separate client streams for improved performance and security
  • Compact metal desktop design with sturdy build and a 3‑year warranty for dependable, low‑maintenance operation
General Information
Brand Name TP-Link
Manufacturer TP-LINK Technologies Co., Ltd
Product Name 9-Port 10/100Mbps Desktop Switch with 8-Port PoE+
Product Type Switch
Product Model TL-SF1009P
Manufacturer Part Number TL-SF1009P
Technical Information
Material Metal
Power Consumption 3.60W
Network Switch Type PoE, Unmanaged
Media Type Supported Twisted Pair
Certifications
TAA Compliant No
Interfaces/Ports
Uplink Port Yes
Network (RJ-45) Yes
Total Number of Network Ports 9
Management & Protocols
Manageable No
Media & Performance
Network Technology 10/100Base-T
Network & Communication
Layer Supported 2
Ethernet Technology Gigabit Ethernet
Networking Standards IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
Others
Model Number Replaces TL-SF1008P
Physical Characteristics
Color Black
Depth 3.9"
Width 6.7"
Height 1.1"
Power Description
PoE Budget 65W
Power Source Power Adapter
PoE (RJ-45) Port Yes
Product Information
Mount Type Desktop Mount
Warranty
Limited Warranty 3-Year
Miscellaneous
Country of Origin CN
Environmentally Friendly Yes
Environmental Certification RoHS
