Hanwha TNB-6030 2MP Public-View Monitoring Camera, 4.6mm Fixed Lens, Black
Key Features
- Discreet public-view design for visible deterrence while blending into indoor environments
- Clear 2MP Full HD monitoring with a 4.6mm fixed lens for reliable identification and situational awareness
- TrueWDR (150 dB) and low-light sensitivity (0.06 lux) to capture usable images in high-contrast and low-light scenes
- On-screen face detection, customizable text overlay and “Recording in progress” indicator to support compliance and behavioral deterrence
- Efficient WiseStream II compression plus HDMI output and SD card support for flexible storage, reduced bandwidth and simple integration into security systems
Quick Specifications
- Product Model
- TNB-6030
- Brand Name
- Hanwha Vision
- Product Name
- 2MP PVM Camera
- Product Type
- PVM Camera
Frequently Bought Together
Hanwha TNB-6030 2MP Public-View Monitoring Camera, 4.6mm Fixed Lens, Black
$433.91
2 items selected
Total: $572.83
Explore the details
Product information
TNB-6030
Overview
Designed for businesses and public spaces that need discreet, lawfully-visible surveillance, the Hanwha Vision TNB-6030 2MP Public-View Monitoring (PVM) camera delivers dependable indoor monitoring without the intimidation of traditional security fixtures. This compact PVM camera produces Full HD 2MP imagery through a 4.6mm fixed lens and supports HDMI output for direct local monitoring. Advanced image processing — including TrueWDR (150 dB) and 0.06 lux low-light performance — ensures clear footage across challenging lighting conditions, while face detection overlays and a blinking “Recording in progress” message provide visual deterrence and help meet transparency requirements. WiseStream II compression reduces network load and storage costs, and onboard SD card support enables local backup. NDAA compliance and robust streaming options make the TNB-6030 a secure, network-friendly choice for retail, transit hubs, healthcare and corporate reception areas. Add a reliable, discreet layer to your security and surveillance strategy — contact sales or order the Hanwha TNB-6030 for professional public-view monitoring.
Features
- Discreet public-view design for visible deterrence while blending into indoor environments
- Clear 2MP Full HD monitoring with a 4.6mm fixed lens for reliable identification and situational awareness
- TrueWDR (150 dB) and low-light sensitivity (0.06 lux) to capture usable images in high-contrast and low-light scenes
- On-screen face detection, customizable text overlay and “Recording in progress” indicator to support compliance and behavioral deterrence
- Efficient WiseStream II compression plus HDMI output and SD card support for flexible storage, reduced bandwidth and simple integration into security systems
| General Information | |
|---|---|
| Brand Name | Hanwha Vision |
| Manufacturer | Hanwha Vision |
| Product Name | 2MP PVM Camera |
| Product Type | PVM Camera |
| Product Model | TNB-6030 |
| Manufacturer Part Number | TNB-6030 |
| Technical Information | |
| Lens Type | Fixed |
| Night Vision | Yes |
| Field of View | Diagonal, Horizontal, Vertical |
| Video Formats | H.264, H.265, MJPEG, MPEG-4 |
| Maximum Aperture | f/2.5 |
| Night Vision Type | Infrared |
| Maximum Frame Rate | 60fps |
| Minimum Focal Length | 4.6mm |
| Connectivity Technology | Wired |
| Effective Camera Resolution | 2MP |
| Camera | |
| Image Sensor Type | CMOS |
| Wide Dynamic Range | Yes |
| Night Vision Distance | 50 ft |
| Certifications | |
| NDAA Compliant | Yes |
| Display & Graphics | |
| Maximum Video Resolution | 1600 x 1200 |
| Environmental Conditions | |
| Operating Humidity | 90% RH |
| Maximum Operating Temperature | 122°F |
| Minimum Operating Temperature | 14°F |
| Exposure | |
| Minimum Illumination | 0.06 lux |
| Longest Shutter Speed | 1/12000 Second |
| Shortest Shutter Speed | 2 Second |
| Interfaces/Ports | |
| HDMI | Yes |
| Network (RJ-45) | Yes |
| Lens | |
| Focal Length | 4.6mm |
| Lens Included | Yes |
| Maximum Focal Length | 4.6mm |
| Network & Communication | |
| Remote Management | Yes |
| Physical Characteristics | |
| Color | Black |
| Depth | 0.98" |
| Width | 9.45" |
| Height | 1.81" |
| Weight | 0.54lb |
| Form Factor | Bullet |
| Power Description | |
| Input Voltage | 12V DC |
| Storage | |
| Storage Type | Memory Card |
| Recording Formats | Full HD |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Features | Back Light Compensation (BLC), Defog, Digital Image Stabilization, Digital Noise Reduction, Face Detection, Gain Control, Highlight Compensation (HLC), Motion Detection, Privacy Masking, Wide Dynamic Range |
| Indoor/Outdoor | Indoor |
| Country of Origin | KR |
