Hanwha XNP-6550RH X-Series 2MP IR PTZ Dome Camera, 55x Optical Zoom Lens, Black/White

SKU: XNP-6550RH Hanwha Vision
Wisenet XNP-6550RH 2 Megapixel Network Camera - Dome
Product images for Hanwha XNP-6550RH X-Series 2MP IR PTZ Dome Camera, 55x Optical Zoom Lens, Black/White. 1 image(s) available. Click on image to view full size.
NDAA Compliant

Key Features

  • Long-range, actionable surveillance with 55x optical zoom and 1,640 ft IR for clear identification across large perimeters
  • Reliable 24/7 monitoring in harsh environments thanks to IP66 weatherproofing and IK10 vandal resistance
  • Bandwidth-efficient H.265/WiseStream II and multiple streaming to reduce network load while preserving image quality
  • Built-in, license-free intelligent video and audio analytics for faster, more accurate alerts and fewer false positives
  • Local failover recording with dual microSD slots (up to 512 GB) ensures continuous capture even if the network is interrupted

Quick Specifications

Brand Name
Hanwha Vision
Manufacturer
Hanwha Group
Product Line
Wisenet
Product Name
2M 55x Network IR PTZ Camera
View Full Technical Specifications

Frequently Bought Together

Product Information Tabs

Overview

Designed for long-range security and critical-area monitoring, the Hanwha Vision XNP-6550RH PTZ dome camera delivers reliable, high-quality surveillance where it matters most. With a massive 55x optical zoom (4.75–261.4 mm) and powerful IR illumination reaching up to 1,640 ft (500 m), operators can identify subjects and incidents across large perimeters day or night. The 2MP sensor provides clear Full HD imagery while H.265 and WiseStream II compression keep bandwidth and storage requirements low—ideal for large-scale networked deployments.

Built to withstand outdoor conditions, this PTZ security camera meets IP66 and IK10 ratings, ensuring uninterrupted monitoring in harsh weather and high-risk locations. License-free intelligent video and audio analytics reduce false alerts and accelerate incident response, while dual microSD slots provide local failover recording for added resilience. Remote management and multiple mounting options make the XNP-6550RH a flexible choice for perimeter, transportation hubs, ports, and critical infrastructure surveillance. Contact your Hanwha Vision dealer to specify or deploy this camera in your next security upgrade.

Features

  • Long-range, actionable surveillance with 55x optical zoom and 1,640 ft IR for clear identification across large perimeters
  • Reliable 24/7 monitoring in harsh environments thanks to IP66 weatherproofing and IK10 vandal resistance
  • Bandwidth-efficient H.265/WiseStream II and multiple streaming to reduce network load while preserving image quality
  • Built-in, license-free intelligent video and audio analytics for faster, more accurate alerts and fewer false positives
  • Local failover recording with dual microSD slots (up to 512 GB) ensures continuous capture even if the network is interrupted
General Information
Brand Name Hanwha Vision
Manufacturer Hanwha Group
Product Line Wisenet
Product Name 2M 55x Network IR PTZ Camera
Product Type Network Camera
Product Model XNP-6550RH
Product Series X
Manufacturer Part Number XNP-6550RH
Technical Information
Lens Type Varifocal
Night Vision Yes
Optical Zoom 55x
Field of View H : 58.6 ?(Wide) ~ 1.23 ?(Tele) / V : 34.8 ?(Wide) ~ 0.71 ?(Tele)
Video Formats H.264, H.265, MJPEG
Maximum Aperture f/1.6
Night Vision Type Infrared
Maximum Frame Rate 60fps
Minimum Focal Length 4.75mm
Connectivity Technology Wired
Effective Camera Resolution 2MP
Camera
Image Sensor Type CMOS
Wide Dynamic Range Yes
Night Vision Distance 1640.42 ft
Certifications
NDAA Compliant Yes
Ingress Protection Rating IP66
Display & Graphics
Maximum Video Resolution 1600 x 1200
Environmental Conditions
Operating Humidity 0.9
Maximum Operating Temperature 131°F (55°C)
Minimum Operating Temperature -40°F (-40°C)
Exposure
Longest Shutter Speed 2 Second
Shortest Shutter Speed 1/12000 Second
Interfaces/Ports
Network (RJ-45) Yes
Lens
Focal Length 4.75-261.4mm
Lens Included Yes
Maximum Focal Length 261.4mm
Network & Communication
Remote Management Yes
Others
Model Number Replaces XNP-6370RH
Physical Characteristics
Color Black, White
Width 9.3"
Height 16.1"
Weight 15.65lb
Durability Dustproof, Impact Resistant, Vandal Resistant, Waterproof
Form Factor PTZ
Power Description
Input Voltage 24V AC
Product Information
Diameter 9.3"
Mount Type Box Mount, Bracket Mount, Ceiling Mount, Corner Mount, Pendant Mount, Pole Mount, Wall Mount
Storage
Storage Type Memory Card
Recording Formats Full HD
Video
Maximum Resolution 1280 x 720
Warranty
Limited Warranty 3-Year
Miscellaneous
Indoor/Outdoor Outdoor
Country of Origin VN
Impact Protection Rating IK10
