Hanwha XNV-6022RM X Series Dome IP Camera, 2MP Mobile Vandal-Resistant IP IR Flat Camera
Special Order Item
This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.
Image of 7
Key Features
- Rugged, vandal-resistant design (IP66 / IK10 / NEMA4X) protects cameras in mobile, outdoor and transit environments for dependable 24/7 security
- Smooth, forensic-quality video at 2MP (1920×1080) and 60 fps with H.265 compression preserves detail while reducing bandwidth and storage
- Low-light and IR performance (0.04 Lux, 15 m IR) keep monitoring active in darkness for continuous surveillance and incident capture
- PoE and M12 connector support simplify installation in vehicles and harsh sites, minimizing cabling and installation time
- Onboard SD storage (up to 256GB) plus 150dB WDR ensures usable evidence in high-contrast scenes and during quick lighting changes
Quick Specifications
- Product Model
- XNV-6022RM
- Brand Name
- Hanwha Vision
- Product Name
- 2M Mobile Vandal-Resistant Network IR Flat Camera
- Product Type
- Network Camera
Frequently Bought Together
Hanwha XNV-6022RM X Series Dome IP Camera, 2MP Mobile Vandal-Resistant IP IR Flat Camera
$452.88
2 items selected
Total: $555.96
Product Information Tabs
Overview
Designed for mobile and harsh-site surveillance, the Hanwha Vision XNV-6022RM X Series Dome IP Camera delivers reliable, high-quality monitoring where durability matters most. This 2MP mobile vandal-resistant IP camera captures smooth 1080p video at up to 60 fps using efficient H.265/H.264 codecs, giving operators clear, actionable footage while conserving network bandwidth. Built to withstand transit and outdoor deployments, the XNV-6022RM features IP66/IK10/NEMA4X-rated housing and M12/PoE connectivity for simplified, secure installations in buses, emergency vehicles, and perimeter sites. Low-light capability (0.04 Lux at F2.0) plus IR illumination to 15 meters maintains continuous night-time surveillance, while 150 dB WDR and onboard SD recording (up to 256GB) ensure usable evidence in high-contrast or fast-moving situations. With a compact 3.6mm fixed lens, motion detection and advanced image stabilization, this Hanwha dome camera reduces false alarms and improves situational awareness for security teams. Ideal for fleet operators, transit authorities, and facility managers looking to upgrade their video monitoring, the XNV-6022RM combines rugged reliability with high-performance imaging. Contact sales to add this camera to your security or mobile monitoring solution.
Features
- Rugged, vandal-resistant design (IP66 / IK10 / NEMA4X) protects cameras in mobile, outdoor and transit environments for dependable 24/7 security
- Smooth, forensic-quality video at 2MP (1920×1080) and 60 fps with H.265 compression preserves detail while reducing bandwidth and storage
- Low-light and IR performance (0.04 Lux, 15 m IR) keep monitoring active in darkness for continuous surveillance and incident capture
- PoE and M12 connector support simplify installation in vehicles and harsh sites, minimizing cabling and installation time
- Onboard SD storage (up to 256GB) plus 150dB WDR ensures usable evidence in high-contrast scenes and during quick lighting changes
| General Information | |
|---|---|
| Brand Name | Hanwha Vision |
| Manufacturer | Hanwha Group |
| Product Name | 2M Mobile Vandal-Resistant Network IR Flat Camera |
| Product Type | Network Camera |
| Product Model | XNV-6022RM |
| Product Series | X |
| Manufacturer Part Number | XNV-6022RM |
| Technical Information | |
| Lens Type | Fixed |
| Night Vision | Yes |
| Field of View | H : 94.8° / V : 49.3° / D : 114.3° |
| Video Formats | H.264, H.265, MJPEG, MPEG-4 AVC |
| Maximum Aperture | f/2 |
| Night Vision Type | Infrared |
| Maximum Frame Rate | 60fps |
| Minimum Focal Length | 3.6mm |
| Effective Camera Resolution | 2MP |
| Camera | |
| Image Sensor Type | CMOS |
| Wide Dynamic Range | Yes |
| Night Vision Distance | 49.21 ft |
| Certifications | |
| NDAA Compliant | Yes |
| Ingress Protection Rating | IP66 |
| Display & Graphics | |
| Maximum Video Resolution | 1600 x 1200 |
| Environmental Conditions | |
| Operating Humidity | 0.9 |
| Maximum Operating Temperature | 131°F (55°C) |
| Minimum Operating Temperature | -22°F (-30°C) |
| Exposure | |
| Longest Shutter Speed | 2 Second |
| Shortest Shutter Speed | 1/12000 Second |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Lens | |
| Focal Length | 3.6mm |
| Lens Included | Yes |
| Maximum Focal Length | 3.6mm |
| Network & Communication | |
| Remote Management | Yes |
| Physical Characteristics | |
| Color | White |
| Depth | 3.9" |
| Width | 3.9" |
| Height | 2" |
| Weight | 10.41oz |
| Durability | Dustproof, Impact Resistant, Vandal Resistant, Waterproof |
| Form Factor | Dome |
| Power Description | |
| Input Voltage | 2.5V DC |
| Product Information | |
| Mount Type | Pole Mount |
| Storage | |
| Storage Type | Memory Card |
| Recording Formats | Full HD |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Miscellaneous | |
| Features | Audio Compression, Audio Detection, Auto Tracking, Defog, Digital Image Stabilization, Gain Control, Motion Detection, Privacy Masking, SD Card Local Storage, White Balance |
| Indoor/Outdoor | Outdoor |
| Impact Protection Rating | IK10 |
