Hanwha XRN-1620B2 X-Series 4K 16-Channel H.265 NVR with AI Search, 140Mbps, 12TB HDD, Black

SKU: XRN-1620B2-12TB Hanwha Vision
Hanwha Techwin 16 Channel NVR
Product images for Hanwha XRN-1620B2 X-Series 4K 16-Channel H.265 NVR with AI Search, 140Mbps, 12TB HDD, Black. 3 image(s) available. Click on image to view full size.
NDAA Compliant

Key Features

  • AI-accelerated search across 16 channels reduces investigation time and speeds incident response.
  • Efficient H.265 and WiseStream compression with 12TB included storage and 8-SATA expandability (up to 80TB) to maximize retention and lower costs.
  • 140 Mbps recording throughput and support for up to 32MP/4K cameras ensure crisp, reliable surveillance and monitoring.
  • Plugin-free web UI and HDMI/VGA dual display simplify deployment, remote management, and multi-monitor monitoring for IT teams.
  • NDAA-compliant, enterprise-grade design built for continuous 24/7 security operations and scalable installations.

Quick Specifications

Product Model
XRN-1620B2
Bandwidth
140 Mbps
Brand Name
Hanwha Vision
Product Name
16 Channel NVR
View Full Technical Specifications

Product Information Tabs

Overview

Streamline enterprise security and accelerate investigations with the Hanwha Vision XRN-1620B2 16-channel 4K NVR. Built as a purpose-driven network video recorder for monitoring critical sites, it pairs AI Search (with Wisenet AI cameras) and WiseStream/H.265 compression to deliver faster incident discovery while reducing storage demands. The unit ships with 12TB raw storage and supports up to 140 Mbps recording throughput—enough bandwidth for multiple high-resolution streams—and expandable 8-SATA bays for future growth (up to 80TB). IT and security teams will appreciate the plugin-free web UI, HDMI/VGA dual display outputs, and remote management tools that simplify deployment and day-to-day administration. With support for up to 32MP camera resolution, fisheye dewarping, and NDAA compliance, the XRN-1620B2 is suited for corporate campuses, retail chains, healthcare facilities, and municipal surveillance projects. Optimize your video retention, speed up investigations, and maintain reliable 24/7 monitoring—contact sales or add to cart to plan your Hanwha Vision surveillance deployment.

Features

  • AI-accelerated search across 16 channels reduces investigation time and speeds incident response.
  • Efficient H.265 and WiseStream compression with 12TB included storage and 8-SATA expandability (up to 80TB) to maximize retention and lower costs.
  • 140 Mbps recording throughput and support for up to 32MP/4K cameras ensure crisp, reliable surveillance and monitoring.
  • Plugin-free web UI and HDMI/VGA dual display simplify deployment, remote management, and multi-monitor monitoring for IT teams.
  • NDAA-compliant, enterprise-grade design built for continuous 24/7 security operations and scalable installations.
General Information
Bandwidth 140 Mbps
Brand Name Hanwha Vision
Manufacturer Hanwha Group
Product Name 16 Channel NVR
Product Type Video Surveillance Station
Product Model XRN-1620B2
Product Series X
Manufacturer Part Number XRN-1620B2-12TB
Technical Information
Video Formats H.264, H.265, MJPEG
Storage Capacity 12TB
Power Consumption 130W
Maximum Frame Rate 480fps
Number of Channels 16
Connectivity Technology Wired
Effective Camera Resolution 32MP
Certifications
NDAA Compliant Yes
Interfaces/Ports
HDMI Yes
Number of USB Ports 1
Network & Communication
Ethernet Yes
Remote Management Yes
Physical Characteristics
Color Black
Depth 16.9"
Width 17.3"
Height 3.5"
Weight 12.59 lb
Storage
Recording Formats 8K
Hard Drive Capacity 12TB
Video
Maximum Resolution 1280 x 720
