Hanwha XRN-1620B2 X-Series 4K 16-Channel H.265 NVR with AI Search, 140Mbps, 12TB HDD, Black
Key Features
- AI-accelerated search across 16 channels reduces investigation time and speeds incident response.
- Efficient H.265 and WiseStream compression with 12TB included storage and 8-SATA expandability (up to 80TB) to maximize retention and lower costs.
- 140 Mbps recording throughput and support for up to 32MP/4K cameras ensure crisp, reliable surveillance and monitoring.
- Plugin-free web UI and HDMI/VGA dual display simplify deployment, remote management, and multi-monitor monitoring for IT teams.
- NDAA-compliant, enterprise-grade design built for continuous 24/7 security operations and scalable installations.
Quick Specifications
- Product Model
- XRN-1620B2
- Bandwidth
- 140 Mbps
- Brand Name
- Hanwha Vision
- Product Name
- 16 Channel NVR
Frequently Bought Together
Hanwha XRN-1620B2 X-Series 4K 16-Channel H.265 NVR with AI Search, 140Mbps, 12TB HDD, Black
$1,952.27
8 items selected
Total: $3,534.06
Product Information Tabs
Overview
Streamline enterprise security and accelerate investigations with the Hanwha Vision XRN-1620B2 16-channel 4K NVR. Built as a purpose-driven network video recorder for monitoring critical sites, it pairs AI Search (with Wisenet AI cameras) and WiseStream/H.265 compression to deliver faster incident discovery while reducing storage demands. The unit ships with 12TB raw storage and supports up to 140 Mbps recording throughput—enough bandwidth for multiple high-resolution streams—and expandable 8-SATA bays for future growth (up to 80TB). IT and security teams will appreciate the plugin-free web UI, HDMI/VGA dual display outputs, and remote management tools that simplify deployment and day-to-day administration. With support for up to 32MP camera resolution, fisheye dewarping, and NDAA compliance, the XRN-1620B2 is suited for corporate campuses, retail chains, healthcare facilities, and municipal surveillance projects. Optimize your video retention, speed up investigations, and maintain reliable 24/7 monitoring—contact sales or add to cart to plan your Hanwha Vision surveillance deployment.
Features
- AI-accelerated search across 16 channels reduces investigation time and speeds incident response.
- Efficient H.265 and WiseStream compression with 12TB included storage and 8-SATA expandability (up to 80TB) to maximize retention and lower costs.
- 140 Mbps recording throughput and support for up to 32MP/4K cameras ensure crisp, reliable surveillance and monitoring.
- Plugin-free web UI and HDMI/VGA dual display simplify deployment, remote management, and multi-monitor monitoring for IT teams.
- NDAA-compliant, enterprise-grade design built for continuous 24/7 security operations and scalable installations.
| General Information | |
|---|---|
| Bandwidth | 140 Mbps |
| Brand Name | Hanwha Vision |
| Manufacturer | Hanwha Group |
| Product Name | 16 Channel NVR |
| Product Type | Video Surveillance Station |
| Product Model | XRN-1620B2 |
| Product Series | X |
| Manufacturer Part Number | XRN-1620B2-12TB |
| Technical Information | |
| Video Formats | H.264, H.265, MJPEG |
| Storage Capacity | 12TB |
| Power Consumption | 130W |
| Maximum Frame Rate | 480fps |
| Number of Channels | 16 |
| Connectivity Technology | Wired |
| Effective Camera Resolution | 32MP |
| Certifications | |
| NDAA Compliant | Yes |
| Interfaces/Ports | |
| HDMI | Yes |
| Number of USB Ports | 1 |
| Network & Communication | |
| Ethernet | Yes |
| Remote Management | Yes |
| Physical Characteristics | |
| Color | Black |
| Depth | 16.9" |
| Width | 17.3" |
| Height | 3.5" |
| Weight | 12.59 lb |
| Storage | |
| Recording Formats | 8K |
| Hard Drive Capacity | 12TB |
| Video | |
| Maximum Resolution | 1280 x 720 |
