AXIS P4705-PLVE 2x2MP Dual-Sensor 360˚ IR Camera with Lightfinder, 3-6mm Lens, White (Replaces P3715-PLVE)

SKU: 02415-001 Axis Communications
Image of Z4-02415001
Product images for AXIS P4705-PLVE 2x2MP Dual-Sensor 360˚ IR Camera with Lightfinder, 3-6mm Lens, White (Replaces P3715-PLVE). 5 image(s) available. Click on image to view full size.

Key Features

  • Complete 360° situational awareness with two 2 MP sensors for seamless, multidirectional surveillance and reduced blind spots
  • Exceptional low-light performance using Axis Lightfinder and Forensic WDR to capture actionable evidence after dark
  • On-edge deep learning (ARTPEC-8 DPU) for smarter analytics, metadata generation and faster forensic search
  • Flexible installation and remote adjustment with varifocal 3–6 mm lenses, PoE support and a single IP address for both sensors
  • Rugged, outdoor-ready design (IP66/67, IK10) that withstands harsh environments while minimizing maintenance costs

Quick Specifications

Product Model
P4705-PLVE
Brand Name
AXIS Communications
Product Line
P
Product Name
AXIS P4705-PLVE
View Full Technical Specifications

Frequently Bought Together

Product Information Tabs

Overview

Designed for expansive, high-confidence surveillance, the AXIS P4705-PLVE panoramic camera by Axis Communications delivers continuous 360° monitoring with two 2 MP sensors to eliminate blind spots and simplify coverage. Built on the ARTPEC-8 platform, this dual-sensor camera includes a deep learning processing unit that enables on-edge analytics, rich metadata and faster forensic searches—reducing investigation time and storage overhead. Lightfinder and Forensic WDR ensure clear, color-accurate images in challenging low-light conditions, while 360° IR illumination and varifocal 3–6 mm lenses provide reliable night-time coverage and remote zoom/focus for fast, cost-effective installation. PoE capability and a single IP address for both heads simplify network deployment, and the IP66/IP67, IK10-rated housing secures outdoor installations against weather and vandalism. Ideal for critical security applications—airports, transit hubs, retail and city surveillance—the AXIS P4705-PLVE streamlines monitoring, improves situational awareness and supports advanced analytics at the edge. Contact sales or add to cart to upgrade your perimeter and site security today.

Features

  • Complete 360° situational awareness with two 2 MP sensors for seamless, multidirectional surveillance and reduced blind spots
  • Exceptional low-light performance using Axis Lightfinder and Forensic WDR to capture actionable evidence after dark
  • On-edge deep learning (ARTPEC-8 DPU) for smarter analytics, metadata generation and faster forensic search
  • Flexible installation and remote adjustment with varifocal 3–6 mm lenses, PoE support and a single IP address for both sensors
  • Rugged, outdoor-ready design (IP66/67, IK10) that withstands harsh environments while minimizing maintenance costs
General Information
Brand Name AXIS Communications
Manufacturer Axis Communications
Product Line P
Product Name AXIS P4705-PLVE
Product Type Fixed dome cameras
Product Model P4705-PLVE
Product Series P47
Manufacturer Part Number 02415-001
Supported Network Protocols IPv6 USGv6, NIST SP500-267
Technical Information
Aperture f/1.9-3.24
Lens Type Varifocal
Night Vision Yes
Optical Zoom 2.5x
Field of View Horizontal, Vertical
Video Formats H.264, H.265, MJPEG, MPEG-4
Maximum Aperture f/1.9
Night Vision Type Infrared
Maximum Frame Rate 60fps
Minimum Focal Length 3.26mm
Connectivity Technology Wired
Effective Camera Resolution 2MP
Camera
Image Sensor Type CMOS
Wide Dynamic Range Yes
Night Vision Distance 49.21 ft
Certifications
Ingress Protection Rating IP66, IP67
Display & Graphics
Image Sensor Size 1/2.8"
Number of Sensors 2
Maximum Video Resolution 1920 x 1080
Environmental Conditions
Operating Humidity 1
Maximum Operating Temperature 122°F (50°C)
Minimum Operating Temperature -22°F (-30°C)
Exposure
Minimum Illumination 0 lux
Longest Shutter Speed 1.5 Second
Shortest Shutter Speed 1/20000 Second
Interfaces/Ports
Network (RJ-45) Yes
Lens
Focal Length 3.26-8.12mm
Lens Included Yes
Minimum Aperture f/3.2
Maximum Focal Length 8.12mm
Memory
Memory Card Supported Yes
Network & Communication
Remote Management Yes
Others
Model Number Replaces 01970-001, P3715-PLVE
Physical Characteristics
Color White
Width 5.2"
Height 3.5"
Weight 2.15lb
Durability Vandal Resistant
Form Factor Panoramic
Power Description
Maximum Power Consumption 17W
Power over Ethernet (PoE) Yes
Product Information
Length 8.2"
Mount Type Ceiling Mount, Conduit Mount, Gang Box Mount, Junction Box Mount, Tripod Mount, Wall Mount
Storage
Storage Type Memory Card
Recording Formats Full HD
Video
Maximum Resolution 1280 x 720
Warranty
Limited Warranty 5-Year
Miscellaneous
Features Day/Night, HTTPS Encryption, Human Detection, Motion Detection, Password Protection, Privacy Masking, SD Card Local Storage, Vehicle Detection, Video Management System, Wide Dynamic Range
Certifications CISPR 32 Class A, CISPR 35, EN 50121-4, EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), IEC 62236-4, KS C 9832 Class A, KS C 9835, RCM AS/NZS CISPR 32 Class A, VCCI Class A
Indoor/Outdoor Outdoor
Country of Origin PL
Impact Protection Rating IK10
Certifications & Standards ONVIF M, ONVIF T
Environmental Certification IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-78, IEC/EN 60529 IP66, IEC/EN 60529 IP67, IEC/EN 62262 IK10, MIL-STD-810H (Method 501.7), MIL-STD-810H (Method 502.7), MIL-STD-810H (Method 505.7), MIL-STD-810H (Method 506.6), MIL-STD-810H (Method 507.6), MIL-STD-810H (Method 509.7), MIL-STD-810H (Method 512.6), NEMA 250 Type 4X, NEMA TS 2 (2.2.7-2.2.9)
