Fire-Lite MS-5UD-3 5-Zone, 24V Fire Alarm Control Panel with Back Box and FLPS-3 Power Supply, 120VAC, 60Hz, 1.0A
Image of 1
Key Features
- Simplified on-site programming with an integral 80-character LCD and keypad for fast commissioning and maintenance
- Built-in DACT and FLPS-3 power supply (120VAC, 60Hz, 1.0A) for dependable off-premises monitoring and reliable power management
- Five-zone, 24V conventional panel supporting System Sensor i3 detectors and standard two- or four-wire devices for flexible device compatibility
- Four synchronized NAC outputs and built-in synchronization for leading notification appliance brands to ensure clear, coordinated evacuation signaling
- Expandable annunciation and relay options for remote monitoring, printer reporting, and integration into larger security or surveillance systems
Quick Specifications
- Product Model
- MS-5UD-3
- Brand Name
- Fire-Lite Alarms by Honeywell
- Product Name
- MS-5UD-3 Burglar Alarm Control Panel
- Product Type
- Fire Alarm Control Panel
Frequently Bought Together
Fire-Lite MS-5UD-3 5-Zone, 24V Fire Alarm Control Panel with Back Box and FLPS-3 Power Supply, 120VAC, 60Hz, 1.0A
$1,175.39
7 items selected
Total: $3,072.15
Explore the details
Product information
MS-5UD-3
Overview
Designed for small to mid-size commercial and institutional sites, the Fire-Lite Alarms MS-5UD-3 fire alarm control panel delivers dependable, easy-to-manage fire detection and monitoring. This five-zone, 24V conventional FACP combines a user-friendly 80-character LCD and keypad with a built-in Digital Alarm Communicator Transmitter (DACT) and an FLPS-3 auxiliary power supply (120VAC, 60Hz, 1.0A) for consolidated power and communications. The panel supplies 3.0 amps of usable current and supports System Sensor i3 series detectors as well as two- and four-wire smoke detectors, pull stations, waterflow and tamper devices — simplifying integration with existing life-safety and security infrastructure. Built-in NAC synchronization and multiple annunciator and relay options let you scale notification and reporting to meet site-specific code and operational needs. Ideal for facilities that require reliable monitoring, coordinated alarm signaling, and future expansion, the MS-5UD-3 streamlines installation and reduces service time. Specify the MS-5UD-3 for retail, office, healthcare, or educational projects where solid fire detection, security integration, and easy maintenance are priorities — contact us to request a quote or technical support.
Features
- Simplified on-site programming with an integral 80-character LCD and keypad for fast commissioning and maintenance
- Built-in DACT and FLPS-3 power supply (120VAC, 60Hz, 1.0A) for dependable off-premises monitoring and reliable power management
- Five-zone, 24V conventional panel supporting System Sensor i3 detectors and standard two- or four-wire devices for flexible device compatibility
- Four synchronized NAC outputs and built-in synchronization for leading notification appliance brands to ensure clear, coordinated evacuation signaling
- Expandable annunciation and relay options for remote monitoring, printer reporting, and integration into larger security or surveillance systems
| General Information | |
|---|---|
| Brand Name | Fire-Lite Alarms by Honeywell |
| Manufacturer | Honeywell International, Inc |
| Product Name | MS-5UD-3 Burglar Alarm Control Panel |
| Product Type | Fire Alarm Control Panel |
| Product Model | MS-5UD-3 |
| Product Series | MS |
| Country of Origin | US |
| Manufacturer Part Number | MS-5UD-3 |
| Technical Information | |
| Panel Control Type | Conventional |
| Connectivity Technology | Wired |
| Number of Standard Zones | 5 |
| Display & Graphics | |
| Display Type | Non-Touchscreen |
| Power Description | |
| Input Voltage | 120V AC |
| Product Replacements & Other Alternatives | |
| Model Number Replaces | MS-2-L8 |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Compatibility | System Sensor's Microprocessor Based i3 Series DetectorsNormally Open Contact DevicesFour Wire Smoke DetectorsTwo Wire Smoke DetectorsWater-flow DevicesTamper SwitchesPull StationsFire-Lite Annunciators:ANN-80ANN-I/OANN-LEDANN-RLYANN-S/PGAN |
